Tp-Link TL-SL1351 [6/12] Chapter 2 installation

Uplink ports, and any port can be simply plugged into a server, a hub, a router or a

switch, using the straight cable or crossover cable. Diagnostic LEDs which display

link status and activity, allowing you to quickly detect and correct problems on the

network.

1.2 Features

¾ Complies with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z (for TL-

SL1351 only) standards

¾ 8/16/24/48 10/100Mbps Auto-Sense RJ45 ports supporting Auto-MDI/MDIX

¾ 2/1/2/2 10/100/1000Mbps Auto-Sense RJ45 ports supporting Auto-MDI/MDIX

¾ 1 SFP(Small Form Pluggable) module interface (For TL-SL1351 only)

¾ Supports Auto MDI / MDIX cable detection on all ports eliminate the need for

crossover cable or Uplink port

¾ Non-blocking switching architecture that forwards and filters packets at full

wire -speed for maximum throughput

¾ Supports MAC address auto-learning and auto-aging

¾ Supports IEEE802.3x flow control for full-duplex model and backpressure for

half-duplex transfer model

¾ LED indicators for monitoring power, link, activity, speed

¾ Internal power supply

Chapter 2 Installation

2.1 Mounting the Switch on a Desk

Before place the Switch on a desk, attach four rubber footpads to the flutes on the

Switch bottom, then lay the Switch on the desktop, where can be have as much as

5kg placed on top.

Note:

Make sure there is a grounded AC outlet within 1.5 meters, and working well.

Make sure there is free space for radiating heat and air. Make sure not to place

anything too heavy on top of the switch.
