2.2 Mounting the Switch in a Rack

The dimension of TL-SL1210/TL-SL1117/TL-SL1226/TL-SL1351 is designed

according to the standard 19'' rack- mountable steel case of Electronic Industries

Association.

Turn off all the equipment connected to the Switch before mounting it in the rack,

then rivet the two “L” brackets onto each side of the Switch, fasten it with screws in

For TL-SL1210, the “L” brackets will differ in size.

Figure 2-1 Rivet the ‘L’brackets onto the Switch

Figure 2-2 Fasten the Switch in the rack
