-7-



LEDs

LED Status Indication

On The Router is powered on

PWR

Off The Router is powered off or power supply is abnormal

Flashing The Router works properly

SYS

On/Off The Router works improperly

On There is a device linked to the corresponding port

Off There is no device linked to the corresponding port

Link/Act

Flashing The corresponding port is transmitting or receiving data

On (Green) The linked device is running at 1000Mbps

On (Yellow) The linked device is running at 100Mbps

Speed

Off

There is no device linked to the corresponding port or the

linked device is running at 10Mbps

On The port is working in DMZ mode

DMZ

Off The port is working in LAN mode



Interface Description

Interface Port Description

WAN 1~2

The WAN port is for connecting the Router to a DSL/Cable

modem or Ethernet by the RJ45 cable

LAN 1~3

The LAN port is for connecting the Router to the local PCs or

switches by the RJ45 cable

DMZ 3 The DMZ port is for connecting the Router to the servers

Console N/A

The Console port is for connecting with the serial port of a

computer or terminal to monitor and configure the Router



Reset button

Use the button to restore the Router to the factory defaults. With the Router powered on, use a pin to

press and hold the Reset button (about 4~5 seconds). After the SYS LED goes out, release the Reset

button. If the SYS LED is flashing with a high frequency about two or three seconds, it means the Router

is restored successfully.
