-56-
Interface B ndwidth
Interface:
tal bandwidth is equal to
Bandwidth:
e
Downstream Bandwidth of WAN port can be configured on WAN page.
a
Displays the current enabled WAN port(s). The To
the sum of bandwidth of the enabled WAN ports.
Displays the bandwidth of each WAN port for transmitting data. The
Upstream
Bandwidth:
Downstream
Upstream Bandwidth of WAN port can be configured on WAN page.
Displays the bandwidth of each WAN port for receiving data. Th
Note:
● The Upstream/Downstream Bandwidth of WAN port you set must not be more than the bandwidth
provided by ISP. Otherwise the Traffic Control will be invalid.
● If there are data flowing into the Router from interface A and out from interface B while the
downstream bandwidth of A is different from the upstream bandwidth of B, then the smaller one
should be considered as the effective bandwidth, and vice versa.
● Click the <View IP Traffic Statistics> button to jump to IP Traffic Statistics page.
Choose the
menu Advanced→Traffic Control→Bandwidth Control to load the following page.
3.3.2.2 Bandwidth Control
On this page, you can configure the Bandwidth Control function.
Figure 3-36 Bandwidth Control
d on this screen: The following items are displaye
