Tp-Link TL-ER6020 [66/168] Link backup

-61-

The following items are displa is screen:

 General

yed on th

Protocol:

Select the protocol for the entry in the drop-down list. If the protocol you

want to set is not in the list, you can add it to the list on 3.3.4.4 Protocol

page.

Source IP:

Enter the source IP range for the entry. 0.0.0.0 - 0.0.0.0 means any IP is

acceptable.

Destination IP:

Enter the destination IP range for the entry. 0.0.0.0 - 0.0.0.0 means any

IP is acceptable.

Source Port:

Enter the source Port range for the entry, which is effective only when the

protocol is TCP, UDP or TCP/UDP. The default value is 1 – 65535, which

means any port is acceptable.

Destination Port:

Enter the destination port range for the entry, which is effective only when

the protocol is TCP, UDP or TCP/UDP. The default value is 1 – 65535,

which means any port is acceptable.

WAN:

Select the WAN port for transmitting packets.

Effective Time:

Specify the time for the entry to take effect.

Status:

Activate or inactivate the entry.

 List of Rules

You can view the information of the entries and edit them by the Action buttons.

16.10.20.29 will be forwarded from

WAN1 port, regardless of the port and protocol. This entry is activated d and will take effect at 8 am to

3.3.4.3 Link Backup

With Link Backup function, the Router will switch all the new sessions from dropped line automatically

to another to keep an always on-line network.

The first entry in Figure 3-40 indicates: All the packets with Source IP

between 192.168.0.100 and

192.168.0.199 and Destination IP between 116.10.20.28 and 1

10 pm from Monday to Friday.
