-86-

Effective Time:

Specify the time for the entry to take effect.

Description:

Give a description for the entry.

Status:

Activate or inactivate the entry.

¾ List of Rules

You can view the information of the entries and edit them by the Action buttons.

The first entry in Figure 4-56 indicates: The group1 is applied with Application Rules. You can click

<View> to view the limited applications in the popup checkbox. The effective time of this entry is

7:00-9:00 on Monday, Tuesday, Friday, Saturday and Sunday. This entry is enabled.

Note:

To set the group and group members, please refer to 4.2.1 Group.

4.6.5.2 Database

On this page, you can upgrade the application database.

Choose the menu Firewall→App Control→Database to load the following page.

Figure 4-57 Database

The database refers to all the applications in the application list on the Application Rules page, you can

download the latest database from http://www.tp-link.com

, Click the <Browse> button and select the

file, and then click the <Upgrade> button to upgrade the database.

4.7 Services

4.7.1 PPPoE Server

The Router can be configured as a PPPoE server to specify account and IP address to users in LAN and

thus you can control the dial-up of users for a high efficiency in network management.

The PPPoE configuration can be implemented on General, IP Address Pool, Account, Exceptional

IP and List of Account pages.
