TL-PA210 AV200 Mini Powerline Adapter
13
) Note:
The parameter information of PIB will restore to the factory defaults after resetting the Powerline
Adapter.
To upgrade the device's firmware, follow these instructions:
1. Download PIB file and firmware upgrade file from TP-LINK website (
http://www.tp-link.com).
2. Enter the path name or click Browse… to select the downloaded files on the computer into the
corresponding blanks.
3. Click the OK button.
)
Note:
Do not turn off the device while the firmware is being upgraded. The device will reboot after the
upgrading has been finished.
¾ “x” Powerline Devices detected: This display all the Powerline Adapter found on the current
logical network. “x” shows the number of remote Powerline Adapter discovered by this Management
Utility.
¾ Network Type: Displayed the type of logical network: “Public” or “Private”.
¾ Autoscan: Shows the scanning status (Default is “ON”).
y Device Name: Shows the default device name. One may redefine or change the name by
clicking on the name and editing in place or by clicking the “Rename” button.
y Password: Shows the current password of the Powerline Adapter.
y Quality: Shows the quality of the Powerline Adapter connection.
y Rate (Mbps): Shows the current transmission rate of the selected Powerline Adapter.
y MAC Address: Shows the Powerline Adapter’s MAC address.
¾ Rename: Click to change the name of the selected Powerline Adapter.
¾ Enter Password: Shows the supplied Powerline Adapter’s password (Initially left blank). To set the
Powerline Adapter password (Which is required when creating a private network), click and select
the device shown in the lower panel and click on the “Enter Password” button. Follow the pop-up
dialog box to complete your password setting.
¾ Add: Click this button to add a remote Powerline Adapter to your network that is not on the lower
panel displayed list. You will advice to locate the passwords for all Powerline Adapter you wish to
manage and add them to the local logical network by clicking the “Add” button. Follow the pop-up
dialog box to complete your setting.
¾ Scan: Click the “Scan” button to perform an immediate search of the Powerline Adapter connected
to the computer. The Management Utility will automatically perform the scanning process and
update the display every few seconds by default.
4.1.1 Rename
This Management Utility allows you to change the name of the listed Powerline Adapter. Click and select
the Powerline Adapter you wish to change from the list, then click on the “Rename” tab and edit in-place
to change the name.
