2. Print Server Installation
Preparation
To meet users’ network printing needs in today’s heterogeneous and multiple protocol
networking environments, the print server supports industrial standard protocols, including
TCP/IP, IPX/SPX, NetBEUI and AppleTalk. This means that the print server supports the
most popular network operating systems today, including NetWare, Windows
95/98/Me/NT/2000/XP/2003, UNIX systems and Macintosh computer. As such, there might
be several ways to deploy the print server on your network.
Supported Networks
Print server supports a variety of network protocols, including TCP/IP, IPX/SPX, NetBEUI
and AppleTalk. In addition, we provide software for network configuration on the following
networks:
․Novell NetWare 3.12, 4.x, 5.x (Bindery and NDS)
․Microsoft Windows 95/98/Me
․Microsoft Windows NT/2000/XP/2003
․Apple EtherTalk
․UNIX /Linux system
․Internet (via Internet Printer Connection software)
Configuration Solution Table
Setup Operating
System
Function Remarks
PSAdmin utility / Setup Wizard
Windows
95/98/Me
Windows
NT/2000/XP/2003
Install a single
network on a
peer-to-peer or
client-server
network
Easy printer installation runs from print server
setup CD
Embedded Web server
Windows
95/98/Me
Windows
NT/2000/XP/2003
Mac OS, Linux…
Remote setup
print server from
private LAN
Follow standard browse, e.g. IE or Netscape
HP Web JetAdmin
Windows Remote Print server solution for continual management of
7
