Tp-Link TD-8810 [57/80] Parental control

TD-8810 ADSL2+ Modem Router User Guide

1. Click the Add button in Figure 4-26 to go to the Add MAC Filt

er page as shown in Figure

4-28.

2. Select the protocol type.

3. Enter the destination MAC address.

4. Enter the source MAC address.

5. Select the frame direction.

6. Select the WAN interfaces.

7. Click Save/Apply to save your settings.

Figure 4-28

To remove an existing entry, follow the steps below.

1. Check the Remove box as shown in Figure 4-26 in the entry you want to remove.

2. Click

the Remove

button.

4.3.4.2 Parental Control

Choose “Securit

y→Parental Control” menu, you can configure the pa

rental control rule in the

screen as shown in Figure 4-29. The Parental Control function can be used to restrict the time

of Internet su

rfing for the child.
