disc surface. It can damage the disc's plastic coating.

• After listening to the CD, always put it into its box. Avoid exposing CDs to

direct sunlight, high temperature or humidity. Do not write on CD's face

side with a pen, as it can damage the disc.

ATTENTION!

The device can play discs of CD - R/RW type, but only if they have been

recorded correctly. Playback of all CD - R/RW discs is not guaranteed by the

manufacturer.

SPECIFICATIONS

Audio

D/À converter: 1-bit D/A converter with 4-times oversampling

Reproduced frequency band: 20-20,000 Hz

ESP/ANTI-SHOCK system: 45 sec CD / 120 sec MP3 memory

Detonation ratio: Below established limits

Number of channels: 2 channels (stereo)

Output capacity: Linear: 0.6 volt (47 kÎhm)

Headphones: 20 milliWatt (32 Ohms)

Headphones: 20 mW (32 Ohms)

Bass Boost effect (100Hz) + 6 dB

MP3

MPEG Speed 32-384 kb/sec

Sampling frequency 8/11.025/12 kHz for MPEG2.5

16/22.05/24 kHz for MPEG2

32/44.1/48 kHz for MPEG1

MP3 Playback Format compatible with ISO 9660 standard

Check up the compact disc recorder's documentation for conformity of its parameters

with the given specifications.

FM Tuner

Frequency band 87.5 - 108 MHz

Intermediate frequency 10.7 ÌHz

Channels separation 25 dB

General

Power supply 2 x 1.2V Ni-MH batteries (66x16.5x6mm)

Network adapter 4.5 V

Power consumption 0.8 Watt (DC 3 V)

Dimensions 132 (W) x 19 (H) x 136 (L) mm

Weight (without batteries) 200 g

THE MANUFACTURER RESERVES THE RIGHT TO CHANGE THE CHARACTERIS-

TICS OF THE DEVICE WITHOUT PRIOR WARNING

SERVICE LIFE OF THE UNIT NOT LESS 5 YEARS
