Vitek VT-3786 [3/10] English
![Vitek VT-3786 [3/10] English](/views2/1042648/page3/bg3.png)
of the current track.
2. Press the BACKWARD (SKIP ) button repeatedly to go back to previous
tracks.
3. Pressthe FORWARD (SKIP ) button repeatedly to go to next tracks.
4. Press and hold either FORWARD (SKIP ) or BACKWARD (SKIP ) button
to search backwards or forwards, at high speed, a particular point of track.
Note:
Low level audio will be heard during the search process to assist in
locating the correct point in the track.
REPEAT PLAYBACK
1. Press the PLAY/PAUSE button (6).
2. To repeat the same track, press the CD Mode button (2) once. The indica-
tor ( 1) will appear on the display and starts single repeat playback until
STOP button (5) is pressed.
3. To repeat the entire CD, press the CD Mode button (2) twice during play-
back.
The indicator ( ALL) will appear on the display, and all tracks will be
repeated.
To cancel the repeat mode, simply press the STOP button (5). The indicator
disappears from the display.
INTRO PLAY
1. Press the PLAY/PAUSE button (6) and after 3 seconds the STOP button
(5).
2. Press the MODE button (2) 3 times to enter the Intro mode, 'INTRO' flash-
es on the display.
3. Press the PLAY/PAUSE button, CD will play the first 10 seconds of each
track on the CD.
4. Press MODE button (2) twice to cancel Intro playback and resume normal
playback.
RANDOM PLAY
1. Press the PLAY/PAUSE button (6).
2. Press the MODE button (2) 4 times to enter the Random mode, 'RAN-
DOM' appears on the display and CD will start playback in randomly order.
3. Press SKIP button to go to next Random track.
Note:
If the Random mode is selected during the playback, the function will
commence once the current track is ended.
ENGLISH
5
orate the performance of the rechargeable batteries.
• DO NOT try to recharge normal (not rechargeable) batteries. They can
explode!
Notes:
• If the rechargeable batteries are being charged for the first time, it will
take approximately 15 hours to be fully charged.
• If the operating time decreases drastically even when the rechargeable
batteries are properly recharged, purchase a new set of rechargeable bat-
teries.
CONNECT THE EARPHONES
Connect the stereo earphones (included) to the Phones jack (11).
CD PLAYBACK
1. Connect the earphones (included) or optional headphones into the Phone
jack.
2. Press the Door Open button (8) to open the CD compartment door.
3. Insert a disc with the label side facing up.
4. Close the CD compartment door until a click is heard.
5. Set the VOLUME control to minimum
.
6. Press the PLAY/PAUSE button (6), the unit power will turn on automatically
and starts playback. The total number of tracks and playing time appears on
the display. During playback, the track number and the elapsed playing time
will be displayed.
7. Adjust the VOLUME control to your desired listening level.
8. To stop playback temporarily, press the PLAY/PAUSE button (6) once.
The elapsed time will flash on the display. Press the PLAY/PAUSE button
again to resume playback.
9. To stop playback, press the STOP (5) button once.
10.To turn the unit off, press the STOP (5) twice.
Notes:
• When the CD door is accidentally opened during playback, "OPEN" will
appear on the display.
• Wait until the disc is fully stopped before pressing the OPEN button.
• This unit can play 3" (8cm) single CDs without an adaptor.
LOCATING A PARTICULAR TRACK OR POINT OF THE TRACK
1. Press the BACKWARD (SKIP ) button once to go back to the beginning
ENGLISH
4
Содержание
- Èíñòðóêöèß ïî ýêñïëóàòàöèè manual instruction 1
- Ìîäåëü vt 3786 1
- English 2
- English 3
- English 4
- English 5
- Audio frequency response 20 hz 20 khz anti shock 45 seconds memory wow and flutter below measurable limits no of channels 2 channels stereo output level line output 0 5 v rms 47 kohm headphone 2x15 mw 32 ohm bass boost effect 6 db 100 hz 6
- English 6
- General power requirements 2 x lr6 um 3 aa alkaline battery dc in 4 v jack accepts ac power adaptor centre positive power consumption 0 w dc 3v dimension approx 127 w x 27 h x 139 d mm weight without batteries 203 g 6
- Service life of the unit not less 5 years 6
- Specifications 6
- The manufacturer reserves the right to change the char acteristics of the device without prior warning 6
- Îðãàíû óïðàâëåíèß 6
- Ïåðåä èñïîëüçîâàíèåì óñòðîéñòâà âíèìàòåëüíî ïðî èòàéòå ðåêîìåíäàöèè èíñòðóêöèè ïî ýêñïëóàòàöèè 6
- Ðóññêèé 6
- Ðóññêèé 7
- Ðóññêèé 8
- Ðóññêèé 9
- Ðóññêèé 10
- Ñîâåòû ïî óñòðàíåíèþ íåèñïðàâíîñòåé 10
- Òåõíè åñêèå õàðàêòåðèñòèêè 10
- Óõîä çà êîìïàêò äèñêàìè 1 óñòðîéñòâî ïðåäíàçíà åíî äëÿ âîñïðîèçâåäåíèÿ êîìïàêò äèñêîâ íà ïðàâîé ñòîðîíå êîòîðûõ èçîáðàæåí ëîãîòèï compact disc digital audio äèñêè áåç ýòîãî ëîãîòèïà íå ñîîòâåòñòâóþò ïðèíÿòûì ñòàíäàðòàì è èõ âîñïðîèçâåäåíèå ìîæåò áûòü íåêà åñòâåííûì 2 ïðè âîñïðîèçâåäåíèè çàãðÿçíåííûõ ïîâðåæäåííûõ èëè äåôîðìèðîâàííûõ äèñêîâ ìîæåò íàáëþäàòüñÿ èñêàæåíèå çâóêà èëè ïîñòîðîííèé øóì äåðæèòå äèñêè òîëüêî çà êðàÿ íå ïðèêàñàéòåñü ê ïîâåðõíîñòè äèñêà 3 ïîñëå èñïîëüçîâàíèÿ äèñêà ïîëîæèòå åãî â ôóòëÿð òîáû íå ïîâðåäèòü åãî ïðè ñëó àéíîì ëàçåðíîì ñ èòûâàíèè 4 íå ïîäâåðãàéòå êîìïàêò äèñêè âîçäåéñòâèþ ïðÿìîãî ñîëíå íîãî ñâåòà âûñîêîé òåìïåðàòóðû èëè âëàæíîñòè â òå åíèå äëèòåëüíîãî âðåìåíè 5 íå íàêëåèâàéòå ñòèêåðû è íå äåëàéòå íàäïèñè íà ïîâåðõíîñòÿõ êîìïàêò äèñêà 6 óñòàíàâëèâàéòå äèñê â îòñåê äëÿ êîìïàêò äèñêîâ äåêîðàòèâíîé ñòîðîíîé ââåðõ çàïèñü ìîæåò ñ èòûâàòüñÿ òîëüêî ñ îäíîé ñòîðîíû êîìïàêò äèñêà î èñòêà äèñêîâ 1 îòïå àòêè ïàëüöåâ è ïûëü ñ çàïèñûâàåìîé ïîâåðõíîñòè äèñêà ñëåäóåò îñòî 10
