The upper designs explain: the MP3 has 11 Catalogs and 172 tracks altogether, but the
tracks' number in each Catalog is different.
For example: Catalog 1 has 16 tracks, Catalog 2 has 14 tracks...... After the whole
Catalogs and tracks shown, the unit will enter playback from the first track.
While playing MP3 the functions of the buttons of PLAY/PAUSE, STOP/OFF,
FORWARD/BACKWARD are the same as CD disc.
SINGLE TRACK REPEAT
In playing mode or stop mode, press the MODE button (13)
once to repeat current playing track, display appears "REPT
1" (In the stop mode, pressing the Play/Pause button again
is required).
SINGLE CATALOG'S TRACKS REPEAT
In playing mode or stop mode, press the MODE button (13)
twice, the whole tracks in the current playing track's Catalog
will be repeated, display appears "REPT DIR" (In the stop
mode, pressing the Play/Pause button again is required).
WHOLE DISC REPEAT
In playing mode or stop mode, press the MODE button (13)
thrice, the whole disc's tracks would be repeatedly playing,
display shows "REPT ALL" (In the stop mode, pressing the
Play/Pause button again is required).
TRACKSELECTING PLAYBACK
• You may press SKIP/ SEARCH button (4 or 3) to select the tracks you require in the
same content, the concrete operations are as same as the operations on CD section.
• During Mp3 disc playing, press ALBUM/10+/ESP button (15) once to select the track
over +10 in the current catalog, adding ten after pressing each time.
• In playing mode, if you are going to select the different tracks in different catalog, you
select catalog first, then choose the tracks you need in the catalog, operations as fol
lows:
1. Press and hold ALBUM/10+/ESP button (15), current catalog appears blinking
in the display.
2. Press the SKIP/SEARCH button (4 or 3) to select catalog.
3. Press the PLAY/PAUSE button (17), the first track of the selected catalog appears.
4. Press the SKIP/SEARCH button (4 or 3) to select the specific track you are going
to listen to.
NOTE:
Take track 2 of catalog 9 as an example:
1. Presume the first playing track is in catalog 1 after read
ing CD, the display showing as follows:
ENGLISH
10
• После использования компактдиски следует хранить в футлярах во избежание появления на
поверхности дисков царапин, которые могут стать причиной пропусков фрагментов
композиций во время воспроизведения.
• Не подвергайте диски воздействию прямых солнечных лучей, высокой влажности или
высоких температур в течение длительных периодов времени. Длительное воздействие
высоких температур на диск может привести к его деформации.
• Запрещается наклеивать бумажные ярлыки, а также наносить надписи на обе стороны диска.
Острые пишущие предметы, а также чернила, использующиеся в некоторых типах
шариковых ручек, могут привести к порче поверхности диска.
ВОСПРОИЗВЕДЕНИЕ ЗАПИСЕЙ НА КОМПАКТ ДИСКАХ
Перед подсоединением или отсоединением наушников,
убедитесь в том, что Вы уменьшили уровень громкости
воспроизведения.
• Вставьте штекер наушников в разъем для подключения
наушников (18).
ВНИМАНИЕ: Прослушивание диска на большой громкости
может причинить вред слуху пользователя.
• Кнопкой (9), откройте крышку загрузочного отсека для
компактдисков.
• Держа диск декоративной стороной вверх, зафиксируйте
его на валу, надавив на него до щелчка.
• Закройте крышку загрузочного отсека, нажмите на кнопку
ВОСПРОИЗВЕДЕНИЕ/ПАУЗА (PLAY/PAUSE) (17), диск начнет
вращаться, на экране появится надпись "
RREEAADDIINNGG"
(СЧИТЫВАНИЕ), после чего на экране появятся обозначения
общего количества дорожек на диске и общего время его
звучания. Воспроизведение автоматически начнется с
первой дорожки.
• Отрегулируйте уровень громкости воспроизведения.
• По желанию активируйте следующую функцию:
Функция усиления низких звуковых частот, кнопка BASS BOOST (22)
Функция усиления низких звуковых частот используется для
поднятия уровня низких частот при прослушивании диска.
• Для временного прекращения воспроизведения, нажмите
на кнопку ВОСПРОИЗВЕДЕНИЕ/ПАУЗА (PLAY/PAUSE) (17).
На экране будет мигать указатель времени, истекшего с
начала воспроизведения дорожки.
Возобновите воспроизведение, повторно нажав на кнопку
ВОСПРОИЗВЕДЕНИЕ/ПАУЗА (PLAY/PAUSE) (17)
• Остановите воспроизведение, нажав на кнопку
СТОП/ВЫКЛ. (STOP/OFF) (2). На экране появится
обозначение общего количества дорожек и общего времени
звучания диска. Повторное нажатие кнопки СТОП/ВЫКЛ.
(STOP/OFF) (2) приведет к отключения устройства от
источника питания.
ФУНКЦИЯ АВТОМАТИЧЕСКОГО ВКЛЮЧЕНИЯ ЭЛЕКТРОПИТАНИЯ
• Электропитание устройства автоматически включается при нажатии на кнопку
ВОСПРОИЗВЕДЕНИЕ/ПАУЗА (PLAY/PAUSE) (17).
РУССКИЙ
21
