1 UNPACKING AND SETUP
Unpacking
Open the shipping carton of the Switch and carefully unpack its
contents. The carton should contain the following items:
♦ One DES-1016R+ or DES-1024R+ 10/100 Fast Ethernet Switch
♦ One AC power cord
♦ This User’s Guide
♦ Four rubber feet with adhesive backing
♦ Screws and two L-type brackets for rack mounting
If any item is found missing or damaged, please contact your local
D-Link reseller for replacement.
Setup
The setup of the Switch can be performed using the following steps:
♦ The surface must support at least 3 kg for the Switch.
♦ The power outlet should be within 1.82 meters (6 feet) of the
device.
♦ Visually inspect the power cord and see that it is fully secured to
the AC power connector.
♦ Make sure that there is proper heat dissipation from and
adequate ventilation around the Switch. Do not place heavy
objects on the Switch.
