10/100 Fast Ethernet Switch User’s Guide
5
Figure 2.2 Attaching the mounting brackets to the 10/100 Fast
Ethernet Switch
Then, use the screws provided with the equipment rack to mount the
Switch in the rack.
Module Installation
An optional two-port fiber module (SC type connector) can be installed in
the front panel. Follow these steps:
First, set up the module, adjusting the jumper settings as desired. The
default setting is full duplex.
Figure 2.3 Jumper settings on the module
