17
CONFIGURATION
Through a web browser, the features and functions of the DGS-1224T
Switch can be configured for optimum use.
Supported web browsers
The embedded Web-based Utility currently supports the following
web browsers:
• Microsoft Internet Explorer ver. 6.0, 5.5
• Mozilla ver. 1.7.12, 1.6
• Firefox ver. 1.5, 1.0.7
• Netscape ver. 8.0.4, 7.2
• Opera ver. 8.5, 7.6
• Safari ver. 2.0.2
Installing the SmartConsole Utility
The following instructions provide guidance to install the
SmartConsole Utility.
1. Insert the Utility CD in the CD-Rom Drive.
2. From the Start menu on the Windows desktop, choose Run.
3. In the Run dialog box, type D:\SmartConsole Utility\setup.exe
(D:\ depends where your CD-Rom drive is located) and click OK.
4. Follow the on-screen instructions to install the utility program.
5. Upon completion, go to Program Files -> SmartConsole Utility
and execute the SmartConsole Utility.
