ABOUT THIS GUIDE
Congratulations on your purchase of the DGS-1224T 24-Port
10/100/1000Mbps Gigabit Ethernet + 2-Port Mini GBIC Web-Smart
Switch. This device integrates 1000Mbps Gigabit Ethernet, 100Mbps
Fast Ethernet and 10Mbps Ethernet network capabilities in a highly
flexible package.
Purpose
This guide discusses how to install and use the configuration functions
of the DGS-1224T Web-Smart Switch.
Terms/Usage
In this guide, the term “Switch” (first letter capitalized) refers to the
DGS-1224T Web-Smart Switch, and “switch” (first letter lower case)
refers to other Ethernet switches. Some technologies refer to terms
“switch”, “bridge” and “switching hubs” interchangeably, and both
are commonly accepted for Ethernet switches.
