20
Help includes: information About the SmartConsole Utility, such as
the software version.
Discovery List
This is the list where all Web-Smart devices on the network are
discovered.
By pressing the Discovery
button, all the Web-Smart devices are
listed in the discovery list.
Double click or press the Add to monitor list
button to select a device
from the Discovery List to the Monitor List.
Definitions of the Discovery List features:
MAC Address: Shows the device MAC Address.
IP Address: Shows the current IP addresses of devices.
Protocol version: Shows the version of the Utility protocol.
Product Name: Shows the device product name.
System Name: Shows the appointed device system name.
DHCP: uses a client/server model to obtain lease of an IP address
from a DHCP server as part of the network boot process.
Location: Shows where the appointed device location.
Trap IP: Shows the IP where the Trap information will be sent.
Subnet Mask: Shows the Subnet Mask set of the device.
Gateway: Shows the Gateway set of the device.
Monitor List
All Web-Smart devices in the Monitor List can be monitored, with
Trap information available to be received for monitoring status
information of the device.
