The symbol “ ” represents a new trap signal, and will disappear after

the event record is reviewed (clicked).

Figure 9 – Trap information

Note: To receive Trap information, the switch must be configured

with Trap IP and Trap Events, available from the Trap Setting menu.

Add Item: Adds a device to the Monitor List manually, by entering

the IP Address of the device to monitor.

Delete Item: Deletes the device from the Monitor List.

Device Setting

Function buttons of the Device Setting section provide several options.

Configuration Setting: In the Configuration Setting, the following

settings are available: Product Name, MAC Address, IP Address,

Subnet Mask, Gateway, Set Trap to (Trapping IP Address), System

name, Location, Password and DHCP ON/OFF (OFF is default).

After selecting the device from the Discovery List or Monitor List and

pressing Configuration Setting, modify the information necessary and

press “Set”.
