9
I
DENTIFYING
E
XTERNAL
C
OMPONENTS
This chapter describes the front panel, rear panel and LED
indicators of the Switch
Front Panel
Front panel view of the Switch
Eight Gigabit Ethernet ports of 10/100/1000Mbps Auto-
Negotiation.
Comprehensive LED indicators that display the conditions of
the Switch and status of the network. A description of these
LED indicators follows (see LED Indicators).
LED Indicators
The LED indicators of the DGS-1008TL include Power,
10/100/1000M Link/Act, and Full-Duplex/Collision. The following
shows the LED indicators for the Switch along with an explanation
of each indicator.
