Description of the appliance

Control panel

Push-button switches

(ON/OFF) – After selecting the wash programme

and temperature, push this button in to start the

machine. (See 8, Indicator light).

– An optional function. When this button is

pressed in, the programme will halt at the end of

the last rinse, and the rinse water will be retained

in the machine. This function is available for the

Synthetics, Delicate and Wool programmes, to

minimise creasing in synthetic fibres.

Once the programme has halted on rinse-hold, if

you wish to end the wash with both emptying of

water and spinning of the load, press the option

button again so it pops out. If you wish to end the

wash by emptying the water without spinning, you

have to advance the programme control knob

manually, to programme setting L. Before you

advance the programme control knob manually, we

recommend that you first press the On/Off button to

switch the machine off (button pops out). Once the

programme control knob is set at L, press the

On/Off button again (button remains in) to complete

the programme.

Knob controls and detergent dispenser

Temperature control – For setting temperatures

between and 90°. Follow care label recom-

mendations.

Programme control – For setting programme

type. See Programme Chart page. 36 - 37.

Detergent dispenser – With separate compart-

ments for detergent and fabric conditioner.

Pre-wash detergent is to be added straight

into the drum.

Indicator light – Comes on approx. 5 seconds

after the ON/OFF button is pressed, when the

door is locked electrically and the machine

starts. The light goes out approx. 2–3 minutes

after the end of the programme and the door

is unlocked.

Space for program chart (Self-adhesive label)

1 2 3 4
