TL-WN722N 150Mbps High Gain Wireless USB Adapter

2) An Ad-Hoc network contains only clients, such as laptops with wireless desktop adapters. All

the adapters must be in Ad-Hoc mode to communicate.

¾ Wireless Mode: Specifies 2.4 GHz 150 Mbps, 2.4 GHz 54 Mbps or 2.4 GHz 11 Mbps

operation in an access point network. The Wireless adapter must match the wireless mode of

the access point with which it associates.

¾ Wireless Mode when Starting an

HAd HocH Network: Specifies 2.4 GHz 54/11 Mbps to start

an Ad Hoc network if no matching network name is found after scanning all available modes.

This mode also allows the selection of the channel that the Wireless Adapter uses. The

channels available depend on the regulatory domain. If the adapter finds no other ad hoc

adapters, the channel that the adapter starts the ad hoc network with will be selected

automatically. The Adapter must match the wireless mode and channel of the clients it

associates.

¾ 802.11 Authentication Mode: Select which mode the Adapter uses to authenticate to an

access point:

• Auto - Automatic causes the adapter to attempt authentication using shared, but

switches it to open authentication if shared fails.

• Open - Open System enables an adapter to attempt authentication regardless of its

WEP settings. It will only associate with the access point if the WEP keys on both the

adapter and the access point match.

• Shared - Shared-key only allows the adapter to associate with access points that have

the same WEP key.

For infrastructure (access point) networks, click Preferred APs… to specify four access points at

most to the client adapter that attempts to be associated to the access points. The four access

points have different priorities; the frontal has the higher priority.

Figure 3-7
