Fluke 975 AirMeter [12/32] Infrared imager
![Fluke 975 AirMeter [12/32] Infrared imager](/views2/1435943/page12/bgc.png)
12
Ordering information
Fluke-INSXT-20
IR InSight, 20MM, XST
Fluke-INSXS-20
IR InSight, 20MM, XS
Includes: Heavy-duty carrying
case, 2 rechargeable battery
packs, battery charger, video
cable, serial/USB download
adapter kit/cable, neck strap,
SmartView reporting and
analysis software on CD and
users manual on CD
12
For detailed product specifications visit: www.fluke.com/thermography
Thermal Imaging
Infrared Imager
Fluke IR InSight
®
Thermal Imagers
The perfect camera for quick,
accurate building surveys.
Combine outstanding image quality and
thermal sensitivity. InSight infrared imagers
are optimized for low contrast thermal applica-
tions encountered in building applications and
easily show problems other infrared cameras
cannot. These easy-to-use cameras include
SmartView
™
software to prepare professional
infrared survey reports.
Key features:
•
160 x 120 focal plane array
•
High resolution, ultra high-quality images
•
Industry-leading thermal sensitivity
(≤ 0.07 °C NETD)
•
Simple, robust one-button operation
•
3.5 inch, 30 bit color, high resolution
high-contrast display
•
SmartView
™
professional report
writing software
SmartView
™
Software
For the XS and XST InSight
®
Thermal Imagers.
Fluke SmartView
™
software is included with
each Fluke InSight Thermal Imager. This pow-
erful software provides all the tools you need
to organize your infrared images.
•
Easily generate customized, professional
reports
•
Images transferred as PGM format and saved
as JPEG or BMP (Microsoft
®
Word compatible)
•
View images in 10 color palette
•
Parameter controls: Emissivity and
background temperature
For detailed specifications, see
www.fluke.com/buildingresources.
Navigate, analyze and
enhance IR images
