September 2006 Rev. 1, 10/08 ©2006, 2008 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. 1
114, 115, 116, and 117
Digital Multimeters
Calibration Information
Introduction
XWWarning
To avoid electric shock or injury, do not perform the performance tests or
calibration adjustment procedures unless qualified to do so.
The information provided in this document is for the use of qualified personnel
only.
The 114, 115, 116, & 117 Calibration Information provides the information necessary to adjust and verify the
performance of the Fluke Models 114, 115, 115C, 116, 116C, 117, and 117C True RMS Multimeters (hereafter
known as the Meter). When specific models are noted in this manual, the “C” version is also included. For example,
when the listed model is 115, the instructions are applicable to the 115C as well.
The following information is included in this document:
• Safety Information and International Electrical Symbols (page 2)
• Specifications (page 3)
• Testing the Fuse (page 5)
• Replacing the Fuse and the Battery (page 6)
• Cleaning (page 7)
• Performance Tests (page 7)
• Calibration Adjustment (page 12)
• Replacement Parts and Accessories (page 17)
• Complete Warranty (page 19)
See the 114, 115, 117 Users Manual or the 115C, 117C Users Manual or the 116 Users Manuals or the 116C Users
Manual for complete operating instructions.
Contact Information
To contact Fluke, call one of the following telephone numbers:
USA: 1-888-99-FLUKE (1-888-993-5853)
Canada: 1-800-36-FLUKE (1-800-363-5853)
Europe: +31 402-675-200
Japan: +81-3-3434-0181
Singapore: +65-738-5655
Anywhere in the world: +1-425-446-5500
Or, visit Fluke's Web site at www.fluke.com
.
To register your product, visit register.fluke.com
Содержание
- 115 116 and 117 1
- 115 116 and 117 calibration information 1
- Calibration information 1
- Contact information 1
- Digital multimeters 1
- Introduction 1
- Safety information 2
- Xw warnings and precautions 2
- Digital multimeters international electrical symbols 3
- General specifications 3
- International electrical symbols 3
- Table 1 lists the international symbols that appear in this document and on the meter 3
- 115 116 and 117 calibration information 4
- Table 2 accuracy specifications 4
- Basic maintenance 5
- Digital multimeters basic maintenance 5
- Figure 1 fuse testing 5
- If the display reads 0l replace the fuse and test again 5
- If the display shows a resistance value in the range of that shown in figure 1 the fuse is good 5
- If the display shows any other value have the meter serviced see contact information earlier in this document 5
- Plug a test lead into the v jack and touch the probe to the 10a jack as shown in figure 1 5
- Set the rotary switch to 5
- Table 3 input characteristics 5
- Testing the fuse 115 117 only 5
- Testing the fuse 115 117 only to test the fuse 5
- Replacing the battery and fuse 6
- Xw warning 6
- Cleaning the meter 7
- Cleaning the meter wipe the case with a damp cloth and mild detergent do not use abrasives or solvents dirt or moisture in the terminals can affect readings 7
- Digital multimeters performance tests 7
- In the performance tests the meter is referred to as the unit under test uut 7
- Performance tests 7
- Required equipment 7
- Required equipment table 4 lists the equipment required to conduct a performance test on the meter 7
- The following performance tests verify the complete operation of the meter and check the accuracy of each meter function against its specifications the recommended calibration interval is 12 months if the meter fails any part of the test calibration adjustment and or repair is indicated 7
- To avoid electric shock do not perform the performance test procedures unless the meter is fully assembled 7
- Xw warning 7
- Backlight test 8
- Keypad test 8
- Preparing for the performance tests 8
- Testing the display 8
- Xw warning 8
- Allow the temperature of the uut to stabilize at room temperature 23 c 5 c 73 f 9 f 9
- Apply the input level for each step listed in table 5 9
- Check the fuses and battery and replace them if necessary refer to testing the fuses and replacing the battery and fuse 9
- Compare the reading on the meter display with the display reading in table 5 9
- Connect the calibrator to the v ω and com input terminals on the meter 9
- If the display reading falls outside of the range shown in table 5 the meter requires calibration adjustment or repair 9
- Testing temperature 116 only 9
- Testing temperature 116 only connect the k type thermocouple to the temperature input of the meter and temperature calibrator to ensure an accurate measurement the meter and the thermocouple connector must be at the same temperature after connecting the thermocouple to the meter allow the junctions to stabilize before recording the displayed reading this can take several minutes depending on temperature gradients 9
- To verify the accuracy of the dmm functions do the following 9
- Turn the rotary switch to the function listed in each step of table 5 9
- Warm up the calibrator as required by its specifications 9
- 115 116 and 117 calibration information 10
- Set calibrator to standby reconfigure leads and program for amps output 10
- Testing the voltalert function 117 only 11
- Calibration adjustment 12
- Calibration adjustment password 12
- Changing the password 12
- Restoring the default password 13
- Xw warning 13
- Calibration adjustment procedure 14
- Meter buttons used in the calibration steps 14
- Digital multimeters calibration adjustment 15
- If the calibration adjustment procedure is not properly completed the meter will not operate correctly 15
- Notes set the calibrator to standby prior to changing the function switch position and after completing adjustment of each function 15
- 115 116 and 117 calibration information 16
- Digital multimeters replacement parts 17
- Figure 6 exploded view of meter 17
- Replacement parts 17
- Table 7 lists the meter s replaceable parts identified in figure 6 17
- 115 116 and 117 calibration information 18
- Battery primary mno2 zn 9v 505mah 6lr61 alkaline 17x26x48mm bulk 19
- Digital multimeters warranty 19
- Warranty 19
