Pressure Gauge
Safety Information
3
Special Conditions for Safe Use
Misuse
If the Product is exposed to overpressure or sudden physical shock (such as being
dropped) examine it for any damage that can cause a safety concern. If necessary, return
the Product for evaluation to Fluke. Refer to the How to Contact Fluke section.
Warning
To prevent possible fire, or personal injury, the Product is
intended for installation only in locations providing adequate
protection against the entry of solid foreign objects or water
capable of impairing safety.
Symbols
Symbols used on the Product and in this manual are explained in Table 1.
Table 1. Symbols
Symbol Meaning Symbol Meaning
Risk of danger. Important
information. See manual.
Conforms to European Union
directives.
Hazardous voltage. Risk of
electrical shock.
Conforms to relevant North
American Safety Standards.
Pressure
This product complies with the
WEEE Directive (2002/96/EC)
marking requirements. The affixed
label indicates that you must not
discard this electrical/electronic
product in domestic household
waste. Product Category: With
reference to the equipment types in
the WEEE Directive Annex I, this
product is classed as category 9
"Monitoring and Control
Instrumentation" product. Do not
dispose of this product as unsorted
municipal waste. Go to Fluke’s
website for recycling information.
Conforms to relevant Australian
standards.
Conforms to ATEX requirements
Conforms to relevant South Korean
EMC Standards.
