11
Please remember that D-Link AirPlus Xtreme G+ wireless devices are pre-
configured to connect together, right out of the box, with their default settings.
You will need broadband Internet access (a Cable or DSL-subscriber line into
your home or office)
Consult with your Cable or DSL provider for proper installation of the modem
Connect the Cable or DSL modem to your broadband router (see the Quick
Installation Guide included with your router.)
If you are connecting a desktop computer to your network, install the D-Link
AirPlus Xtreme G+ DWL-G520+ wireless PCI adapter into an available PCI slot
on your desktop computer. You may also install the DWL-520+.
(See the Quick Installation Guide included with the network adapter.)
Install the drivers for the D-Link DWL-G650+ wireless Cardbus adapter into a
laptop computer. You may also install DWL-650+.
(See the Quick Installation Guide included with the network adapter.)
Getting Started
For a typical wireless setup at home (as shown above), please do the
following:
55
55
5
Setting up a Wireless Infrastructure Network
44
44
4
22
22
2
11
11
1
33
33
3
DWL-G520+ with
Destop Computer
