12
General operations
Power button
Press any button (except OPEN and EJECT) or insert disc to switch the unit on. Press POWER button to switch
the unit off.
Volume control
Rotate VOL knob on the front panel to adjust volume level.
Audio settings adjustment
Press SEL button shortly and repeatedly to select a mode: VOL (volume) => BAS (bass) => TRB (treble) =>
BAL (balance) => FAD (fader). Rotate VOL knob to adjust each mode.
Note: When DSP is on, bass and treble adjustment is not available.
Caution: In each mode, the waiting time is several seconds, and when the waiting time is over, it returns to
the last display mode of radio or disc playback mode.
Mode selection
Press MOD button to choose a sound source: RADIO => AUX => CD => SD/MMC => USB.
Loudness control
Press and hold BAND/LOUD button; LOUD ON will be displayed meaning that bass output emphasize function
is activated. To deactivate the function press and hold the button again.
Information display
Press DISP button to operate as the conversion of each display mode as follows:
- In case of receiving a RDS station
In radio mode: PS -> CT -> FREQ -> P TY
In CD mode: CD -> CT -> (ID3 TAG) -> PS -> FREQ -> PTY
* In case of no receiving CT or PTY Information, the display shows as “NO CLOCK” or “NO PTY”.
- In case of receiving a non RDS station
In radio mode: “NO CLOCK” -> FREQ-> “NO PTY”
In CD mode: CD -> “NO CLOCK” -> FREQ -> “NO PTY”
