7
Hardware address (MAC address)
Brand, type, and version information.
The regulatory domain for which the Access Point has
been configured (factory setting). Note that it is illegal
to use the Access Point outside the designated domain.
See Regulatory Domains for details.
The IP address and the hostname of the Access Point.
The radio channel number. The permissible channels
depend on the Regulatory Domain.
An optional description field for easy reference.
Network Settings Dialog
Figure 3: Network Settings Dialog Box
Selecting the Edit/Network Settings from the menu item (or clicking the corresponding
toolbar button, shown in Figure 3) pops up the Network Settings dialog. Use this dialog
to inform APManager(tm) about your network configuration. APManager(tm) needs this
information to be able to scan for Access Points.
Add your network addresses (subnets) by entering the correct information in the Network
address, mask and default gateway fields in the dialog, and clicking the Set button for
each network/subnet. To view the details of a particular network, click on the Address
field in the list. Click the Remove button to delete a network from the list.
If the computer on which APManager is running is connected to all your networks
directly, you can try Auto Add Local Networks to insert them in the list. If subnetting is
being used on the network, the network addresses and subnet masks generated by this
function may not be correct and should be adjusted manually.
