Using the Conﬁguration Menu

To congure the DWL-3260AP, use a computer which is connected to the DWL-3260AP with an

Ethernet cable (see the

Network Layout diagram).

First, disable the

Access the Internet using a proxy server function. To disable this function,

go to

Control Panel > Internet Options > Connections > LAN Settings and uncheck the

enable box.

Start your web browser program (Internet Explorer, Netscape Navigator

™

) .

Type the IP address and http port of the DWL-3260AP in the address eld

(http://192.168.0.50) and press

Enter. Make sure that the IP addresses of the

DWL-3260AP and your computer are in the same subnet.

After the connection is established, you will see the user identication window as shown.

Note: If you have changed the default IP address assigned to the DWL-3260AP, make sure to

enter the correct IP address.

 

 





Type admin in the User Name eld

Leave the Password eld blank

Click

Note: If you have changed the password, make sure to enter the correct password.
