55
Using the AP Manager
Selecting Devices
The AP Manager allows you to congure multiple devices all at once. To select a single device,
simply click on the device you want to select. To select multiple devices, hold down the
Ctrl key
while clicking on each additional device. To select an entire list, hold the
Shift key, click on the
rst AP on the list and then click on the last AP on the list.
IP Configuration
You can assign an IP address to an AP or assign IP addresses to multiple
AP’s by clicking on this button after selecting the device(s).
Select the AP that you want to assign an IP address to and click the IP button. Enter the IP address
and IP netmask for the selected device and click OK.
You can congure multiple AP’s with IP addresses all at once. Click on the IP button after you’ve
selected all of the AP’s you want to assign an IP address. Enter the IP address you want to assign
the rst unit and the AP manager will automatically assign sequential IP addresses.
