Инструкция по эксплуатации Страница: 34

Gigabyte GA-MA790XT-UD4P Инструкция по эксплуатации онлайн [34/112] 41653

GA-MA790XT-UD4P Motherboard - 34 -

Содержание

Ga ma790xt ud4p 1
User s manual 1
Copyright 3
Disclaimer 3
Documentation classifications 3
Identifying your motherboard revision 3
Box contents 6 optional items 6 ga ma790xt ud4p motherboard layout 7 block diagram 8 4
Chapter 1 hardware installation 9 4
Chapter 2 bios setup 35 4
Table of contents 4
Chapter 3 drivers installation 57 5
Chapter 4 unique features 61 5
Chapter 5 appendix 73 5
Box contents 6
Optional items 6
Ga ma790xt ud4p 7
Ga ma790xt ud4p motherboard layout 7
Block diagram 8
1 installation precautions 9
Chapter 1 hardware installation 9
2 product specifications 10
3 1 installing the cpu 13
3 installing the cpu and cpu cooler 13
3 2 installing the cpu cooler 15
4 1 dual channel memory configuration 16
4 installing the memory 16
4 2 installing a memory 17
5 installing an expansion card 18
6 setup of ati crossfire 19
A system requirements 19
B connecting the graphics cards 19
C configuring the graphics card driver 19
Configuration 19
7 installing the sata bracket 20
8 back panel connectors 21
Coaxial s pdif out connector 21
Ieee 1394a port 21
Optical s pdif out connector 21
Ps 2 keyboard and ps 2 mouse port 21
Rj 45 lan port 21
Usb port 21
Center subwoofer speaker out jack orange 22
Line in jack blue 22
Line out jack green 22
Mic in jack pink 22
Rear speaker out jack black 22
Side speaker out jack gray 22
9 internal connectors 23
2 atx_12v_2x4 atx 2x4 12v power connector and 2x12 main power connector 24
Ga ma790xt ud4p motherboard 24 24
To meet expansion requirements it is recommended that a power supply that can withstand high power consumption be used 500w or greater if a power supply is used that does not provide the required power the result can lead to an unstable or unbootable system the power connectors are compatible with power supplies with 2x2 12v and 2x10 power connectors when using a power supply providing a 2x4 12v and a 2x12 power connector remove the protective covers from the 12v power connector and the main power connector on the motherboard do not insert the power supply cables into pins under the protective covers when using a power supply providing a 2x2 12v and a 2x10 power connector 24
With the use of the power connector the power supply can supply enough stable power to all the components on the motherboard before connecting the power connector first make sure the power supply is turned off and all devices are properly installed the power connector possesses a foolproof design connect the power supply cable to the power connector in the correct orientation the 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the computer will not start 24
4 5 cpu_fan sys_fan1 sys_fan2 pwr_fan fan headers 25
Be sure to connect fan cables to the fan headers to prevent your cpu and system from overheating overheating may result in damage to the cpu or the system may hang these fan headers are not configuration jumper blocks do not place a jumper cap on the headers 25
Fdd floppy disk drive connector 25
Hardware installation 25 25
The motherboard has a 4 pin cpu fan header cpu_fan a 4 pin sys_fan1 and two 3 pin sys_fan2 system fan headers and a 3 pin power fan header pwr_fan most fan headers possess a foolproof insertion design when connecting a fan cable be sure to connect it in the correct orientation the black connector wire is the ground wire the motherboard supports cpu fan speed control which requires the use of a cpu fan with fan speed control design for optimum heat dissipation it is recommended that a system fan be installed inside the chassis 25
This connector is used to connect a floppy disk drive the types of floppy disk drives supported are 360 kb 720 kb 1 mb 1 4 mb and 2 8 mb before connecting a floppy disk drive be sure to locate pin 1 of the connector and the floppy disk drive cable the pin 1 of the cable is typically designated by a stripe of different color 25
Ide ide connector 26
Sata2_0 1 2 3 4 5 sata 3gb s connectors controlled by amd sb750 26
A raid 0 or raid 1 configuration requires at least two hard drives please connect the l shaped end of the sata 3gb s cable to your sata hard drive 27
Gsata2_0 1 sata 3gb s connectors controlled by gigabyte sata2 27
Hardware installation 27 27
Pwr_led system power led header 27
The sata connectors conform to sata 3gb s standard and are compatible with sata 1 gb s standard each sata connector supports a single sata device the gigabyte sata2 controller supports raid 0 raid 1 and jbod refer to chapter 5 configuring sata hard drive s for instructions on configuring a raid array 27
This header can be used to connect a system power led on the chassis to indicate system power status the led is on when the system is operating the led keeps blinking when the system is in s1 sleep state the led is off when the system is in s3 s4 sleep state or powered off s5 27
F_panel front panel header 28
Cd_in cd in connector 29
F_audio front panel audio header 29
Hardware installation 29 29
The front panel audio header supports hd audio by default if your chassis provides an ac 97 front panel audio module refer to the instructions on how to activate ac 97 function ality via the audio software in chapter 5 configuring 2 4 5 7 channel audio audio signals will be present on both of the front and back panel audio connections simultaneously if you want to mute the back panel audio only supported when using an hd front panel audio module refer to chapter 5 configuring 2 4 5 7 channel audio some chassis provide a front panel audio module that has separated connectors on each wire instead of a single plug for information about connecting the front panel audio module that has different wire assignments please contact the chassis manufacturer 29
The front panel audio header supports intel high definition audio hd and ac 97 audio you may connect your chassis front panel audio module to this header make sure the wire assignments of the module connector match the pin assignments of the motherboard header incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it 29
You may connect the audio cable that came with your optical drive to the header 29
Ga ma790xt ud4p motherboard 30 30
Spdif_in s pdif in header 30
Spdif_out s pdif out header 30
This header supports digital s pdif in and can connect to an audio device that supports digital audio out via an optional s pdif in cable for purchasing the optional s pdif in cable please contact the local dealer 30
This header supports digital s pdif out and connects a s pdif digital audio cable provided by expansion cards for digital audio output from your motherboard to certain expansion cards like graphics cards and sound cards for example some graphics cards may require you to use a s pdif digital audio cable for digital audio output from your motherboard to your graphics card if you wish to connect an hdmi display to the graphics card and have digital audio output from the hdmi display at the same time for information about connecting the s pdif digital audio cable carefully read the manual for your expansion card 30
Do not plug the ieee 1394 bracket 2x5 pin cable into the usb header prior to installing the usb bracket be sure to turn off your computer and unplug the power cord from the power outlet to prevent damage to the usb bracket 31
Do not plug the usb bracket cable into the ieee 1394a header prior to installing the ieee 1394a bracket be sure to turn off your computer and unplug the power cord from the power outlet to prevent damage to the ieee 1394a bracket to connect an ieee 1394a device attach one end of the device cable to your computer and then attach the other end of the cable to the ieee 1394a device ensure that the cable is securely connected 31
F_1394 ieee 1394a header 31
F_usb1 f_usb2 usb headers 31
Hardware installation 31 31
The header conforms to ieee 1394a specification the ieee 1394a header can provide one ieee 1394a port via an optional ieee 1394a bracket for purchasing the optional ieee 1394a bracket please contact the local dealer 31
The headers conform to usb 2 1 specification each usb header can provide two usb ports via an optional usb bracket for purchasing the optional usb bracket please contact the local dealer 31
Ci chassis intrusion header 32
Com serial port header 32
Ga ma790xt ud4p motherboard 32 32
The com header can provide one serial port via an optional com port cable for purchasing the optional com port cable please contact the local dealer 32
This motherboard provides a chassis detection feature that detects if the chassis cover has been removed this function requires a chassis with chassis intrusion detection design 32
Battery 33
Clr_cmos clearing cmos jumper 33
Chapter 2 bios setup 35
1 startup screen 36
A the logo screen default 36
B the post screen 36
2 the main menu 37
Bios setup program function keys 37
Sample bios version f4e 37
Advanced bios features 38
Exit without saving 38
Integrated peripherals 38
Keys for the main menu only 38
Load fail safe defaults 38
Load optimized defaults 38
Mb intelligent tweaker m i t 38
Pc health status 38
Power management setup 38
Save exit setup 38
Set supervisor password 38
Set user password 38
Standard cmos features 38
3 mb intelligent tweaker m i t 39
39 bios setup 39
Advanced clock calibratioin 39
Allows you to select the ec firmware version when advanced clock calibration is enabled after the selection select save exit setup in the bios main menu and then press y a message which says bios is updating ec firmware don t turn off or reset system will appear 39
Ec firmware selection 39
Whether the system will work stably with the overclock overvoltage settings you made is dependent on your overall system configurations incorrectly doing overclock overvoltage may result in damage to cpu chipset or memory and reduce the useful life of these components this page is for advanced users only and we recommend you not to alter the default settings to prevent system instability or other unexpected results inadequately altering the settings may result in system s failure to boot if this occurs clear the cmos values and reset the board to default values when the system voltage optimized item blinks in red it is recommended that you set the system voltage control item to auto to optimize the system voltage settings 39
Advanced clock calibration 40
Cpu clock ratio 40
Cpu frequency mhz 40
Cpu host clock control 40
Cpu northbridge freq 40
Ht link frequency 40
Ht link width 40
Pcie clock mhz 40
Set memory clock 40
Value all cores 40
Value core 0 value core 1 value core 2 value core 3 40
41 bios setup 41
Allows you to set memory control mode 41
Cas latency 41
Cpu host clock control cpu frequency mhz set memory clock memory clock 41
Dcts mode 41
Ddr3 timing items 41
Dram configuration 41
Ganged sets memory control mode to single dual channel 41
Manual allows all ddr3 timing items below to be configurable options are auto default manual 41
Memory clock 41
Minimum ras active time 41
Options are 1t default 2t 41
Options are 90ns default 110ns 160ns 300ns 350ns 41
Options are auto default 15t 30t 41
Options are auto default 4t 12t 41
Options are auto default 4t 7t 41
Options are auto default 5t 12t 41
Ras to cas r w delay 41
Row precharge time 41
T 2t command timing 41
The settings under the four items above are synchronous to those under the same items in the mb intelligent tweaker m i t 41
This option is configurable only when set memory clock is set to manual 41
Trfc0 for dimm1 41
Twtr command delay 41
Unganged sets memory control mode to two single channel default 41
X4 0 sets memory clock to x4 0 41
X5 3 sets memory clock to x5 3 41
X6 6 sets memory clock to x6 6 41
X8 0 sets memory clock to x8 0 41
Cpu nb vid control 42
Cpu voltage control 42
Ddr3 voltage control 42
Normal cpu vcore 42
Northbridge volt control 42
Precharge time 42
Ras to ras delay 42
Row cycle time 42
Southbridge volt control 42
System voltage control 42
Trfc1 for dimm3 42
Trfc2 for dimm2 42
Trfc3 for dimm4 42
Write recovery time 42
4 standard cmos features 43
43 bios setup 43
Access mode sets the hard drive access mode options are auto default chs lba large 43
Access mode sets the hard drive access mode options are auto default large 43
Extended ide drive configure your ide sata devices by using one of the two methods below auto lets bios automatically detect ide sata devices during the post default none if no ide sata devices are used set this item to none so the system will skip the detection of the device during the post for faster system startup 43
Ide channel 0 1 master slave 43
Ide channel 0 1 master slave configure your ide sata devices by using one of the two methods below auto lets bios automatically detect ide sata devices during the post default none if no ide sata devices are used set this item to none so the system will skip the detection of the device during the post for faster system startup 43
Ide channel 2 3 4 master slave 43
Ide hdd auto detection 43
Sets the system date the date format is week read only month date and year select the desired field and use the up arrow or down arrow key to set the date 43
Sets the system time for example 1 p m is 13 0 0 select the desired field and use the up arrow or down arrow key to set the time 43
To autodetect the parameters of the ide sata device on this channel 43
Drive a 44
Floppy 3 mode support 44
Halt on 44
Memory 44
45 bios setup 45
5 advanced bios features 45
Amd k8 cool quiet control 45
Auto lets the amd cool n quiet driver dynamically adjust the cpu clock and vid to reduce heat output from your computer and its power consumption default 45
Disabled disables this function 45
First second third boot device 45
Hard disk boot priority 45
Password check 45
Setup a password is only required for entering the bios setup program default 45
Specifies whether a password is required every time the system boots or only when you enter bios setup after configuring this item set the password s under the set supervisor user password item in the bios main menu 45
System a password is required for booting the system and for entering the bios setup program 45
To accept options are floppy ls120 hard disk cdrom zip usb fdd usb zip usb cdrom usb hdd legacy lan disabled 45
To exit this menu when finished 45
Virtualization 45
Virtualization allows a platform to run multiple operating systems and applications in independent partitions with virtualization one computer system can function as multiple virtual systems default disabled 45
Away mode 46
Backup bios image to hdd 46
Full screen logo show 46
Hdd s m a r t capability 46
Init display first 46
47 bios setup 47
6 integrated peripherals 47
Ahci configures the sata controller to ahci mode advanced host controller interface ahci is an interface specification that allows the storage driver to enable advanced serial ata features such as native command queuing and hot plug 47
As sata type the mode depends on the onchip sata type settings 47
Configures the operating mode of the integrated sata controller 47
Enables or disables the integrated ide controller default enabled 47
Enables or disables the integrated sata controller default enabled 47
Enables or disables the onboard audio function default auto if you wish to install a 3rd party add in audio card instead of using the onboard audio set this item to disabled 47
Ide disables raid for the sata controller and configures the sata controller to pata mode default 47
Native ide allows the sata controller to operate in native ide mode default enable native ide mode if you wish to install operating systems that support native mode 47
Onboard audio function 47
Onchip ide channel 47
Onchip sata controller 47
Onchip sata port4 5 mode amd sb750 south bridge sata2_4 sata2_5 connectors 47
Onchip sata type amd sb750 south bridge sata2_0 sata2_3 connectors 47
Raid enables raid for the sata controller 47
This option is configurable only when onchip sata type is set to raid or ahci configures the operating mode of the integrated sata2_4 sata2_5 connectors 47
Onboard gsata ii ctrl gigabyte sata2 chip gsata2_0 gsata2_1 connectors 48
Onboard gsata ii ctrl mode gigabyte sata2 chip gsata2_0 gsata2_1 connectors 48
Onboard lan boot rom 48
Onboard lan function 48
Smart lan lan cable diagnostic function 48
Legacy usb storage detect 49
Onboard 1394 function 49
Onboard serial port 1 49
Onchip usb controller 49
Usb ehci controller 49
Usb keyboard support 49
Usb mouse support 49
7 power management setup 50
Acpi suspend type 50
Allows the system to be awakened from acpi s3 sleep state by a wake up signal from the installed usb device default enabled 50
Allows the system to be awakened from an acpi sleep state by a wake up signal from a modem that supports wake up function default disabled 50
Configures the way to turn off the computer in ms dos mode using the power button 50
Delay 4 sec press and hold the power button for 4 seconds to turn off the system if the power button is pressed for less than 4 seconds the system will enter suspend mode 50
Ga ma790xt ud4p motherboard 50 50
Instant off press the power button and then the system will be turned off instantly default 50
Modem ring resume 50
Note supported on window 50
Operating system only 50
S1 pos enables the system to enter the acpi s1 power on suspend sleep state in s1 sleep state the system appears suspended and stays in a low power mode the system can be resumed at any time 50
S3 str enables the system to enter the acpi s3 suspend to ram sleep state default in s3 sleep state the system appears to be off and consumes less power than in the s1 state when signaled by a wake up device or event the system resumes to its working state exactly where it was left off 50
Soft off by power button 50
Specifies the acpi sleep state when the system enters suspend 50
Usb wake up from s3 50
Ac back function 51
Hpet support 51
Kb power on password 51
Pme event wake up 51
Power on by alarm 51
Power on by keyboard 51
Power on by mouse 51
8 pc health status 52
Case opened 52
Displays the detection status of the chassis intrusion detection device attached to the motherboard ci header if the system chassis cover is removed this field will show yes otherwise it will show no to clear the chassis intrusion status record set reset case open status to enabled save the settings to cmos and then restart your system 52
Ga ma790xt ud4p motherboard 52 52
Keeps or clears the record of previous chassis intrusion status enabled clears the record of previous chassis intrusion status and the case opened field will show no at next boot default disabled 52
Reset case open status 52
Cpu smart fan control 53
Cpu smart fan mode 53
Cpu system power fan fail warning 53
Cpu warning temperature 53
Current cpu system power fan speed rpm 53
Current system cpu temperature 53
Current voltage v vcore ddr3 1 v 3 v 12v 53
System smart fan control 53
10 load optimized defaults 54
9 load fail safe defaults 54
Ga ma790xt ud4p motherboard 54 54
Key to load the optimal bios default settings the bios defaults settings helps the system to operate in optimum state always load the optimized defaults after updating the bios or after clearing the cmos values 54
Key to load the safest bios default settings in case system instability occurs you may try to load fail safe defaults which are the safest and most stable bios settings for the motherboard 54
11 set supervisor user password 55
12 save exit setup 56
13 exit without saving 56
Ga ma790xt ud4p motherboard 56 56
To return to the bios setup main menu 56
1 installing chipset drivers 57
Chapter 3 drivers installation 57
2 application software 58
3 technical manuals 58
4 contact 59
5 system 59
6 download center 60
1 xpress recovery2 61
A installing windows vista and partitioning the hard drive 61
Before you begin 61
Chapter 4 unique features 61
Installation and configuration 61
System requirements 61
B accessing xpress recovery2 62
C using the backup function in xpress recovery2 62
D using the restore function in xpress recovery2 63
E removing the backup 63
F exiting xpress recovery2 63
2 1 updating the bios with the q flash utility 64
2 bios update utilities 64
A before you begin 64
B updating the bios 65
Ga ma790xt ud4p motherboard 66 66
To exit q flash and reboot the system as the system boots you should see the new bios version is present on the post screen 66
To load bios defaults 66
To load bios defaults system will re detect all peripherals devices after a bios update so we recommend that you reload bios defaults 66
To save settings to cmos and exit bios setup the procedure is complete after the system restarts 66
2 2 updating the bios with the bios utility 67
A before you begin 67
B using bios 67
C after updating the bios 67
3 easytune 6 68
Tabs information 68
The easytune 6 interface 68
4 easy energy saver 69
Meter mode button information table 69
The easy energy saver interface a meter mode 69
B total mode 70
C stealth mode 70
Total mode button information table 70
5 q share 71
Directions for using q share 71
Options descriptions 71
6 time repair 72
Preference screen 72
System restore 72
1 1 configuring amd sb750 sata controllers 73
1 configuring sata hard drive s 73
A installing sata hard drive s in your computer 73
Before you begin 73
Chapter 5 appendix 73
To configure sata hard drive s follow the steps below 73
B configuring sata controller mode in bios setup 74
Figure 1 74
Ga ma790xt ud4p motherboard 74 74
Make sure to configure the sata controller mode correctly in system bios setup 74
Step 2 save changes and exit bios setup 74
The bios setup menus described in this section may differ from the exact settings for your motherboard the actual bios setup menu options you will see shall depend on the motherboard you have and the bios version 74
To enter bios setup during the post power on self test ensure onchip sata controller is enabled under integrated peripherals to enable raid for the sata2_0 1 2 3 connectors set onchip sata type to raid to enable raid for the sata2_4 sata2_5 connectors set onchip sata type to raid and set onchip sata port4 5 type to as sata type figure 1 74
C configuring raid set in raid bios 75
Figure 4 76
Figure 5 76
Ga ma790xt ud4p motherboard 76 76
To enter the define ld window figure 4 the define ld selection from the main menu allows users to begin the process of manually defining the drive elements and raid levels for one or multiple disk arrays attached to the amd sb750 controller 76
To enter the raid configuration menu figure 5 76
Delete an array the delete array menu option allows for deletion of disk array assignments 78
Deleting an existing disk array could result in loss of data record all array information including the array type the disk members and stripe block size in case you wish to undo a deletion 78
Figure 9 78
Ga ma790xt ud4p motherboard 78 78
To return to main menu 78
1 2 configuring gigabyte sata2 sata controller 79
A installing sata hard drive s in your computer 79
Appendix 79 79
Attach one end of the sata signal cable to the rear of the sata hard drive and the other end to available sata port on the motherboard on this motherboard the gsata2_0 and gsata2_1 ports are supported by the gigabyte sata2 sata controller then connect the power connector from your power supply to the hard drive 79
B enabling the sata controllers and configuring hard drive mode in bios setup 79
Figure 1 79
Make sure to enable the sata controllers and configure hard drive mode in system bios setup 79
Step 2 save changes and exit bios setup 79
The bios setup menus described in this section may differ from the exact settings for your motherboard the actual bios setup menu options you will see shall depend on the motherboard you have and the bios version 79
To enter bios setup during the post in bios setup go to integrated peripherals ensure that onboard gsata ii ctrl is enabled then set onboard gsata ii ctrl mode to raid figure 1 if you do not want to create raid set this item to ide or ahci depending on your need 79
C configuring a raid array in raid bios 80
Enter the raid bios setup utility to configure a raid array skip this step and proceed to the installation of windows operating system for a non raid configuration 80
Figure 2 80
Figure 3 80
Ga ma790xt ud4p motherboard 80 80
To enter the gigabyte sata2 raid bios utility 80
To see detailed information about the selected hard drive 80
Appendix 81 81
Figure 4 81
Figure 5 81
On the create raid disk drive item then the create new raid screen appears figure 4 81
The create new raid block displays all the items that need to be set for creating an array figure 5 81
To move onto the next step 81
Figure 6 82
Figure 7 82
Ga ma790xt ud4p motherboard 82 82
To abort 82
A small window displaying the array information will appear in the center of the screen figure 9 83
Appendix 83 83
Figure 8 83
Figure 9 83
When finished the new raid array will be displayed in the raid disk drive list block figure 8 83
Figure 10 84
Figure 11 84
Ga ma790xt ud4p motherboard 84 84
Now you may proceed to create the sata raid ahci driver diskette and the installation of the sata raid ahci driver and operating system 84
To cancel 84
1 3 making a sata raid ahci driver diskette for windows xp 85
Required for ahci and raid mode 85
1 4 installing the sata raid ahci driver and operating system 86
A installing windows xp 86
B installing windows vista 88
Appendix 93 93
Gigagyte sata2 sata controller turn off your computer and replace the failed hard drive with a new one use either the gigabyte sata2 raid bios utility or the gigabyte raid configurer utility in the operating system to perform the rebuild 93
To start the raid rebuilding process the rebuilding progress is displayed at the bottom of the screen when done the status of the array will display as normal 93
2 1 configuring 2 4 5 7 channel audio 95
2 configuring audio input and output 95
A configuring speakers 95
B configuring sound effect 96
C activating an ac 97 front panel audio module 96
D muting the back panel audio for hd audio only 96
2 2 configuring s pdif in out 97
A s pdif in 97
B s pdif out 98
2 3 enabling the dolby home theater function 99
2 4 configuring microphone recording 100
Enabling stereo mix 101
2 5 using the sound recorder 102
A recording sound 102
B playing the recorded sound 102
3 1 frequently asked questions 103
3 troubleshooting 103
3 2 troubleshooting procedure 104
Ga ma790xt ud4p motherboard 104 104
If you encounter any troubles during system startup follow the troubleshooting procedure below to solve the problem 104
Appendix 105 105
If the procedure above is unable to solve your problem contact the place of purchase or local dealer for help or go to the support downloads technical service zone page to submit your question our customer service staff will reply you as soon as possible 105
4 regulatory statements 106
Our commitment to preserving the environment 106
Regulatory notices 106
Restriction of hazardous substances rohs directive statement 106
Waste electrical electronic equipment weee directive statement 106
Weee symbol statement 106
China restriction of hazardous substances table 107
Appendix 111 111
Contact us 111
Ga ma790xt ud4p motherboard 112 112
Gigabyte global service system 112
To submit a technical or non technical sales marketing question please link to http ggts gigabyte com tw then select your language to enter the system 112
