Appendix- 93 -
• GIGAGYTE SATA2 SATA controller:
Turn off your computer and replace the failed hard drive with a new one. Use either the GIGABYTE
SATA2 RAID BIOS utility or the GIGABYTE RAID CONFIGURER utility in the operating system to
perform the rebuild.
Rebuilding with the GIGABYTE SATA2 RAID BIOS utility
Step 1:
When the message "Press <Ctrl-G> to enter RAID Setup Utility" appears, press <Ctrl> + <G> to enter the
utility. In the Main Menu block, select Rebuild Mirror Drive and press <Enter>. The selection bar will
move to the degraded array. Press <Enter> again.
GIGABYTE Technology Corp. PCIE-to-SATAII/IDE RAID Controller BIOS v1.06.59
[ Main Menu ]
Create RAID Disk Drive
Delete RAID Disk Drive
Revert HDD to Non-RAID
Solve Mirror Conflict
Rebuild Mirror Drive
Save And Exit Setup
Exit Without Saving
[ RAID Disk Drive List ]
[TAB]-Switch Window []-Select ITEM [ENTER]-Action [ESC]-Exit
[ Hard Disk Drive List ]
Model Name Capacity Type/Status
HDD0: ST3120026AS 120 GB RAID Inside
HDD1: ST3120026AS 120 GB Non-RAID
Model Name RAID Level Capacity Status Members(HDDx)
RDD0: GRAID 1-Mirror 120 GB Degraded 0?
Step 2:
The selection bar will then move to new hard drive in the Hard Disk Drive List block. Press <Enter>
to start the RAID rebuilding process. The rebuilding progress is displayed at the bottom of the screen.
When done, the status of the array will display as Normal.
GIGABYTE Technology Corp. PCIE-to-SATAII/IDE RAID Controller BIOS v1.06.59
[ Main Menu ]
Create RAID Disk Drive
Delete RAID Disk Drive
Revert HDD to Non-RAID
Solve Mirror Conflict
Rebuild Mirror Drive
Save And Exit Setup
Exit Without Saving
[ RAID Disk Drive List ]
Rebuilding....35%, please wait....
[ Hard Disk Drive List ]
Model Name Capacity Type/Status
HDD0: ST3120026AS 120 GB RAID Inside
HDD1: ST3120026AS 120 GB Non-RAID
Model Name RAID Level Capacity Status Members(HDDx)
RDD0: GRAID 1-Mirror 120 GB Degraded 0?
