- 39 - BIOS Setup
2-3 MB Intelligent Tweaker(M.I.T.)
• Whether the system will work stably with the overclock/overvoltage settings you made is dependent on your overall
system configurations. Incorrectly doing overclock/overvoltage may result in damage to CPU, chipset, or memory
and reduce the useful life of these components. This page is for advanced users only and we recommend you not
to alter the default settings to prevent system instability or other unexpected results. (Inadequately altering the
settings may result in system's failure to boot. If this occurs, clear the CMOS values and reset the board to default
values.)
• When the System Voltage Optimized item blinks in red, it is recommended that you set the System Voltage
Control item to Auto to optimize the system voltage settings.
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
MB Intelligent Tweaker(M.I.T.)
Advanced Clock Calibratioin [Press Enter]
CPU Clock Ratio [Auto] 2800Mhz
CPU NorthBridge Freq. [Auto] 2000Mhz
CPU Host Clock Control [Auto]
x CPU Frequency(MHz) 200
PCIE Clock (MHz) [Auto]
HT Link Width [Auto]
HT Link Frequency [Auto]
Set Memory Clock [Auto]
x Memory Clock x6.66 1333Mhz
DRAM Configuration [Press Enter]
********
System Voltage Optimized
********
System Voltage Control [Auto]
x DDR3 Voltage Control Normal
x NorthBridge Volt Control Normal
x SouthBridge Volt Control Normal
x CPU NB VID Control Normal
x CPU Voltage Control Normal
Normal CPU Vcore 1.2500V
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
Advanced Clock Calibratioin
CMOS Setup Utility-Copyright (C) 1984-2009 Award Software
Advanced Clock Calibratioin
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
EC Firmware Selection [Normal]
Advanced Clock Calibratioin [Disabled]
x Value (All Cores) -2%
x Value (Core 0) -2%
x Value (Core 1) -2%
x Value (Core 2) -2%
x Value (Core 3) -2%
EC Firmware Selection
Allows you to select the EC firmware version when Advanced Clock Calibration is enabled.
After the selection, select Save & Exit Setup in the BIOS Main Menu and then press Y. A message
which says "BIOS Is Updating EC Firmware!!! Don't Turn Off Or Reset System" will appear.
