Remington HC6550 Голубой; Черная [8/160] English

• Themeshpanelishingedandcanbeswungopenwhenthechamberis

removed from the clipper.

• Ensurethemeshpanelisdrybeforere-usingtheclipper.

• We recommend oiling the blades after cleaning with a little sewing machine

oil.

, WASHABLE CLEANING

, NOTE: Only the blades on this clipper and the mesh panel of the vacuum

chamber can be washed under running water.

• To remove the blades ensure the unit is o. Grab underneath the blade with

your thumb and push the top of the blade away from the clipper.

• Use enough force to move the blade o the retaining snaps and rotate the

blade o the bottom tab. Pull the blade away from the clipper.

• To reattach once the blades are cleaned and dry, align the bottom of the

blade with the bottom blade housing tab and push down onto the retaining

snaps until the blade clicks into place.

• Do not run the entire unit under the tap, only the blade set is meant to be

submerged in water.

• Place a few drops of cutter or sewing machine oil onto the blades. Wipe o

excess oil.

BATTERY REMOVAL

• The battery must be removed from the appliance before it is scrapped.

• The appliance must be disconnected from the supply mains when removing

the battery.

• Ensure the clipper is discharged of all power.

• Remove vacuum chamber and blade.

• Using a small screwdriver, remove 3 screws top of clipper where the vacuum

chamber was.

• Using a small screwdriver, remove 2 screws bottom of unit near the back

(plug end).

• Pry the top housing starting from the back (plug end). There are snaps

helping to hold down the housing at the side grips on both sides. Once the

snaps are disengaged then rotate housing up this will allow the panel to be

removed o the latches near the front (blade end).

• The PCB and batteries are located underneath this panel.

• Cut or break the wire stamps on the both end of the batteries and remove

the batteries.

• The battery is to be disposed of safely.

ENGLISH
