Model Name
ANT24-1800 ANT24-1801 ANT24-1500 ANT24-2100
Signal directivity
Directional
Directional
Omni-directional Directional
Application range
Outdoor
Outdoor
Outdoor Outdoor
Gain (Without cable loss)
18dBi
18dBi
15dBi 21dBi
Approximate Range at 1 Mbps / 11Mbps *
( Work with Indoor AP )
5Km / 2Km 5Km / 2Km 2.5Km / 1Km 8Km / 3Km
Approximate Range at 1Mbps/ 11 Mbps *
(Work with Outdoor AP)
8Km / 3Km 8Km / 3Km 3.5Km / 1.5Km 10Km / 4.5Km
Half power beam width **
H15 V15 H15 V15
H360 V8 H5 V8
Pigtail cable length
NA
NA
NA NA
Antenna fixed connector
N-jack
N-jack
N-jack N-jack
Surge protector for outdoors
Included
Included
Included Included
Default extension cable length
50cm
50cm
3M 3M
Default mounting configuration
Wall/ pole Pole
Pole Pole
Antenna-kit weight (Kg)
3.2Kg
4.22Kg
2.5Kg 4Kg
Optional accessories
Ultra low loss cable
For ANT24-CB series
Ultra low loss cable
For ANT24-CB series
Ultra low loss cable
For ANT24-CB series
Ultra low loss cable
For ANT24-CB series
Optional antenna cable kits
ANT24-IDU series
ANT24-ODU series
ANT24-DLK series
ANT24-IDU series
ANT24-ODU series
ANT24-DLK series
ANT24-IDU series
ANT24-ODU series
ANT24-DLK series
ANT24-IDU series
ANT24-ODU series
ANT24-DLK series
*1.Extended range reference based on RF-Output Power 15dbm( Indoor AP), 19 ( outdoor AP) with default cable loss,
*2.The transmission distance range might depend on the two same spec antennas with default cable loss
*3. Effective range based on EIRP( Effected Isotropic Radiation Power. = device output power + antenna gain – cable lost )
**HPBW: Half Power Beam Width. H : horizontal plane pattern, V : vertical plane pattern
The actual Indoor range will be effected by users’ physical environment. The above figures are reference.
