III. Power Supply Removal

1. Please rst read Chapter II. Warning! Important Safety Information above.

2. Make certain that your system is entirely powered o; set the power supply’s AC power switch to

the “O” (OFF) position and disconnect the power cord from the AC outlet.

3. Open the computer case (please refer to the manufacturer’s user manual).

4. Carefully disconnect all the power supply’s connectors from the mainboard and the peripherals.

5. Unscrew the mounting screws securing the power supply unit to the back panel of the case.

6. Carefully remove the power supply from the case.

IV. Power Supply Installation

1. Place the Seasonic power supply into the space provided within the case and use the four

mounting screws provided in the accessory bag to secure it to the back panel of the case. Do not

over-tighten the screws.

a. For power supplies with a built-in fan, the fan side top cover should be facing the mainboard.

(Depending on the type of computer case, this can mean either upwards or downwards

facing fan cover.)
