b. For fanless power supplies, Sea Sonic recommends to mount fanless power supplies into

the computer case with their ventilation cover facing UPWARDS. However, there are extra

mounting-screw holes provided on the back of the power supply to allow for reverse

mounting, if necessary

2. Mainboard connection:

a. DO NOT force the connectors into place; the connectors are “keyed” so they can only t one

way. Make sure the connectors lock in their place securely.

b. Connect the power supply end of the 24/20-Pin convertible connector to the appropriate

receptor on the power supply unit.

c. Connect the mainboard end of the 24/20-Pin convertible connector to the mainboard.

Depending on the mainboard, you may need to either attach or detach the 4-Pin module of

the 24/20-Pin connector.

d. Connect the + 12 V 4-Pin connector and the EPS + 12 V connector, if applicable.

e. If your system requires dual EPS + 12 V connectors, please connect the 8-Pin end of the

second CPU 8-Pin connector into the appropriate 8-Pin receptor on the power supply unit.

Then connect the mainboard end of this 8-Pin connector to the mainboard.

3. Peripheral components connection:

a. Connect one end of the peripheral cable to the power supply and the other end to the

component.
