2
G Operating instruction
Thank you for choosing aHama product.
Take your time and read the following instructions and information completely.Please keep
these instructions in asafe place for futurereference. If you sell the device, please pass
these operating instructions on to the new owner.
1. Explanation of Warning Symbols and Notes
Warning
This symbol is used to indicate safety instructions or to draw your attention to specic
hazards and risks.
Note
This symbol is used to indicate additional information or important notes.
2. Package Contents
• TV wall bracket
• Installation kit (see contents, Fig. 1)
• These operating instructions
Note
Please check that the installation kit is complete beforeinstalling the
bracket and ensurethat none of the parts arefaulty or damaged.
3. Safety Notes
Warning
• Given the multitude of wall structures, the supplied mounting kit is unable to
cover every option.
• It occasionally happens that the screws for attaching the terminal device to the
wall bracket aretoo long.
• Please note that the supplied wall plugs arefor use with concrete brick and solid
brick walls only.
• Read the operating instructions for your terminal device beforeattempting to
mount it. The instructions provide information about the type and measurements
of suitable fastening materials.
• If the wall on which the bracket is to be mounted is made of different material
types and construction types to those specied, purchase suitable mounting
materials from aspecialised dealer.
• Never apply force during mounting. This can damage your end device or wall
bracket.
• If in doubt, have this product mounted by aqualied technician -donot attempt
to mount it yourself!
• Do not mount the product above locations wherepersons might linger.
• Once you have mounted the product and the attached load, check that they are
suciently secureand safe to use.
• Youshould repeat this check at regular intervals
(at least every three months).
• When doing so, ensurethat the product does not exceed its maximum permitted
carrying capacity and that no load exceeding the maximum permitted dimensions is
attached.
• Make surethat the product is loaded symmetrically.
• Maintain the necessary safety clearance around the attached load (depending on the
model).
• In the event of damage to the product, remove the attached load and stop using the
product.
4. Intended use and specifications
• The bracket is used for wall mounting at panel displays for non-commercial, private
household use.
• The bracket is only intended for use within buildings.
• Use the bracket only for the intended purpose.
• The mount is intended for mounting the Samsung Q7, Q8 and Q9 TV sets to the wall.
Maximum load bearing capacity: 50 kg
Screen size: 81,0 -165,0 cm (US: 32” -65”)
Depth: 0,6 –7,2 cm
Angle: -32° (depends on the device)
Wall mounting plate dimensions: 52,0 x8,5 cm
5. Installation requirements and installation
Note
• Only mount the TV wall bracket with the help of asecond person. Get the support
and help you need.
• The same mounting kit is included with all of our TV wallbrackets. Depending on
the product and mounting type, you may not need to use the entiremounting kit.
Unneeded screws and other small parts may be left over,even if the wall bracket
is properly mounted. Keep these leftover parts with the operating instructions in a
safe place, just in case you might need them later on (e.g. should you move, sell
the product, mount the wall bracket in adifferent location, buy anew TV,etc).
Warning
• Beforeinstalling the bracket, ensurethat the wall on which the television is to be
mounted is suitable for the weight and make surethat no electrical wires, water,
gas or other lines arelocated at the installation location.
• Please note that the provided wallanchors areonly approved for concrete and
solid brick walls.
• Observe the other warnings and safety instructions.
• Proceed step-for-step in accordance with the illustrated installation instructions (Fig.
1ff.).
6. Setting and maintenance
Note
Only adjust the TV wall bracket with the help of asecond person. Get the support and
help you need.
• Adjust the TV set’sdistance from the wall as desired (see Fig. 4).
• Screws do not have to be loosened to adjust the angle. The tilting resistance can be
adjusted using the screws on the side of the vertical TV plate.
• Check that the bracket is secureand safe to use at regular intervals (at least every three
months). Only use water or standardhousehold cleaners for cleaning.
7. Warranty Disclaimer
Hama GmbH &CoKG assumes no liability and provides no warranty for damage resulting
from improper installation/mounting, improper use of the product or from failureto
observe the operating instructions and/or safety notes.
8. Service and Support
Please contact Hama Product Consulting if you have any questions about this product.
Hotline: +49 9091 502-115 (German/English)
Further support information can be found here:
www.hama.com
