Hardware Installation - 10 -
1-2 Product Specications
CPU
Support for AM3 processors:
AMD Phenom
™
II processor/ AMD Athlon
™
II processor
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport Bus
2000 MT/s
Chipset
NVIDIA
®
nForce 520LE
Memory
4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
(Note 1)
Dual channel memory architecture
Support for DDR3 1666(O.C.)/1333/1066 MHz memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and
memory modules.)
Audio
Realtek ALC892R codec
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF In/Out
Support for CD In
LAN
Realtek RTL8201EL chip (10/100 Mbit)
Expansion Slots
1 x PCI Express x16 slot, running at x16
2 x PCI Express x1 slots
4 x PCI slots
Storage Interface
Chipset:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 2 x SATA 3Gb/s connectors supporting up to 2 SATA 3Gb/s devices
- Support for SATA RAID 0 and RAID 1
iTE IT8720 chip:
- 1 x oppy disk drive connector supporting up to 1 oppy disk drive
USB
Chipset
- Up to 8 USB 2.0/1.1 ports (4 on the back panel, 4 via the USB brackets
connected to the internal USB headers)
Internal
1 x 24-pin ATX main power connector
Connectors
1 x 4-pin ATX 12V power connector
1 x oppy disk drive connector
1 x IDE connector
2 x SATA 3Gb/s connectors
1 x CPU fan header
1 x system fan header
1 x power fan header
1 x front panel header
1 x front panel audio header
1 x CD In connector
1 x S/PDIF In header
1 x S/PDIF Out header
"*" The GA-M52LT-D3 adopts All-Solid Capacitor design.
