- 11 - Hardware Installation
(Note 1) Due to Windows 32-bit operating system limitation, when more than 4 GB of physical memory is
installed, the actual memory size displayed will be less than 4 GB.
(Note 2) Whether the CPU/system fan speed control function is supported will depend on the CPU/system
cooler you install.
(Note 3) Available functions in EasyTune may differ by motherboard model.
Internal
2 x USB 2.0/1.1 headers
Connectors
1 x clearing CMOS jumper
Back Panel
1 x PS/2 keyboard port
Connectors
1 x
PS/2 mouse port
1 x coaxial S/PDIF Out connector
1 x parallel port
1 x serial port
4 x USB 2.0/1.1 ports
1 x RJ-45 port
6 x audio jacks (Center/Subwoofer Speaker Out/Rear Speaker Out/
Side Speaker Out/Line In/Line Out/Microphone)
I/O Controller
iTE IT8720 chip
Hardware Monitor
System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU/System overheating warning
CPU/System fan fail warning
CPU/System fan speed control
(Note 2)
BIOS
2 x 8 Mbit ash
Use of licensed AWARD BIOS
Support for DualBIOS
™
PnP 1.0a, DMI 2.0, SM BIOS 2.4, ACPI 1.0b
Unique Features
Support for @BIOS
Support for Q-Flash
Support for Xpress BIOS Rescue
Support for Download Center
Support for Xpress Install
Support for Xpress Recovery2
Support for EasyTune
(Note 3)
Support for Auto Green
Support for ON/OFF Charge
Bundled Software
Norton Internet Security (OEM version)
Operating System
Support for Microsoft
®
Windows
®
7/Vista/XP
Form Factor
ATX Form Factor; 30.5cm x 21.6cm
