BIOS Setup - 54 -
PCI1 IRQ Assignment
Auto BIOS auto-assigns IRQ to the rst PCI slot. (Default)
3,4,5,7,9,10,11,12,14,15 Assigns IRQ 3,4,5,7,9,10,11,12,14,15 to the rst PCI slot.
2-8 PnP/PCI Congurations
CMOS Setup Utility-Copyright (C) 1984-2010 Award Software
PnP/PCICongurations
PCI1IRQAssignment [Auto]
higf
: Move Enter: Select +/-/PU/PD: Value F10: Save ESC: Exit F1: General Help
F5: Previous Values F6: Fail-Safe Defaults F7: Optimized Defaults
Item Help
Menu Level
