Hardware Installation - 10 -
1-2 Product Specications
CPU
Support for AM3 processors:
AMD Phenom
™
II processor/ AMD Athlon
™
II processor
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport Bus
5200 MT/s
Chipset
North Bridge: AMD 880G
South Bridge: AMD SB850
Memory
4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
(Note 1)
Dual channel memory architecture
Support for DDR3 1800(O.C.)/1333/1066 MHz memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and
memory modules.)
Onboard Graphics
Integrated in the North Bridge:
- 1 x D-Sub port
- 1 x DVI-D port
(Note 2) (Note 3)
- 1 x HDMI port
(Note 3)
Audio
Realtek ALC892 codec
High Denition Audio
2/4/5.1/7.1-channel
Support for Dolby
®
Home Theater
Support for S/PDIF In/Out
Support for CD In
LAN
1 x Realtek RTL8111D/E chip (10/100/1000 Mbit)
Expansion Slots
1 x PCI Express x16 slot, running at x16 (PCIEX16)
(Note 4)
1 x PCI Express x16 slot, running at x4 (PCIEX4)
1 x PCI Express x1 slot
(All PCI Express slots conform to PCI Express 2.0 standard.)
1 x PCI slot
Multi-Graphics
Support for ATI Hybrid CrossFireX
™
technology
Technology
Storage Interface
South Bridge:
- 5 x SATA 6Gb/s connectors (SATA3_0~SATA3_4) supporting up to 5 SATA
6Gb/s devices
- 1 x eSATA 3Gb/s connector on the back panel supporting up to 1 SATA
3Gb/s device
- Support for SATA RAID 0, RAID 1, RAID 5, RAID 10, and JBOD
JMicron JMB368 chip:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
iTE IT8720 chip:
- 1 x oppy disk drive connector supporting up to 1 oppy disk drive
