Hardware Installation - 10 -
1-2 ProductSpecications
CPU AM3+ Socket:
- AMD AM3+ FX processor
- AMD AM3 Phenom
™
II processor/ AMD Athlon
™
II processor
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport
Bus
5200 MT/s
Chipset
North Bridge: AMD 880G
South Bridge: AMD SB710
Memory 2 x 1.5V DDR3 DIMM sockets supporting up to 8 GB of system memory
* Due to Windows 32-bit operating system limitation, when more than 4 GB of physical
memory is installed, the actual memory size displayed will be less than 4 GB.
Dual channel memory architecture
Support for DDR3 1666 (O.C.)/1333/1066 MHz memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
North Bridge:
- 1 x D-Sub port
- 1 x DVI-D port, supporting a maximum resolution of 1920x1200
* The DVI-D port does not support D-Sub connection by adapter.
- 1 x HDMI port, supporting a maximum resolution of 1920x1200
* Simultaneous output for DVI-D and HDMI is not supported.
Audio Realtek ALC889 codec
High Denition Audio
2/4/5.1/7.1-channel
* To congure 7.1-channel audio, you have to use an HD front panel audio module
and enable the multi-channel audio feature through the audio driver.
Support for S/PDIF Out
LAN 1 x Realtek RTL8111E chip (10/100/1000 Mbit)
Expansion Slots 1 x PCI Express x16 slot, running at x16
1 x PCI Express x1 slot
(All PCI Express slots conform to the PCI Express 2.0 standard.)
2 x PCI slots
Multi-Graphics
Technology
Support for AMD Hybrid CrossFireX
™
technology
Storage Interface South Bridge:
- 4 x SATA 3Gb/s connectors supporting up to 4 SATA 3Gb/s devices
- Support for RAID 0, RAID 1, RAID 10, and JBOD
