Содержание

Copyright 3
Disclaimer 3
Identifying your motherboard revision 3
Box contents optional items 4
Chapter 1 hardware installation 4
Chapter 2 bios setup 9 4
Ga 880gm usb3l ga 880gm d2h motherboard layout ga 880gm usb3l ga 880gm d2h motherboard block diagram 4
Table of contents 4
Chapter 3 drivers installation 5 5
Chapter 4 unique features 9 5
Chapter 5 appendix 1 5
Box contents 6
Optional items 6
Ga 880gm usb3l ga 880gm d2h 7
Ga 880gm usb3l ga 880gm d2h motherboard layout 7
J only for ga 880gm usb3l k only for ga 880gm d2h 7
Ga 880gm usb3l ga 880gm d2h motherboard block diagram 8
1 installation precautions 9
Chapter 1 hardware installation 9
2 product specifications 10
2 productspecifications 10
3 1 installing the cpu 13
3 installing the cpu and cpu cooler 13
3 2 installing the cpu cooler 15
4 1 dual channel memory configuration 16
4 1 dualchannelmemoryconfiguration 16
4 installing the memory 16
4 2 installing a memory 17
5 installing an expansion card 18
6 setup of the amd hybrid crossfire 19
6 setup of the amd hybrid crossfirex configuration 19
A system requirements 19
B connecting the graphics cards 19
C bios setup 19
Configuration 19
D configuringthegraphicsdriver 19
7 back panel connectors 20
D sub port 20
Dvi d por 20
Hdmi por 20
Ps 2 keyboard mouse port 20
Usb 2 1 port 20
A dualdisplayconfigurations 21
B playbackofhddvdandblu raydiscs 21
Line in jack blue 21
Line out jack green 21
Mic in jack pink 21
Rj 45 lan port 21
Usb 3 2 port j 21
8 internal connectors 22
2 atx_12v atx 2x2 12v power connector and 2x12 main power connector 23
23 hardware installation 23
To meet expansion requirements it is recommended that a power supply that can withstand to meet expansion requirements it is recommended that a power supply that can withstand high power consumption be used 500w or greater if a power supply is used that does not provide the required power the result can lead to an unstable or unbootable system 23
With the use of the power connector the power supply can supply enough stable power to all the components on the motherboard before connecting the power connector first make sure the power supply is turned off and all devices are properly installed the power connector possesses a foolproof design connect the power supply cable to the power connector in the correct orientation the 12v power connector mainly supplies power to the cpu if the 12v power connector is not connected the computer will not start 23
4 cpu_fan sys_fan fan headers 24
Clr_cmos clearing cmos jumper 24
Bat battery 25
Sata2_0 1 2 3 sata 3gb s connectors 25
F_panel front panel header 26
27 hardware installation 27
F_audio front panel audio header 27
Front panel audio module refer to the instructions on how to activate ac 97 functionality via the audio software in chapter 5 configuring 2 4 5 7 channel audio audio signals will be present on both of the front and back panel audio connections simultane 27
Instead of a single plug for information about connecting the front panel audio module that has different wire assignments please contact the chassis manufacturer 27
Ously if you want to mute the back panel audio only supported when using an hd front panel audio module refer to chapter 5 configuring 2 4 5 7 channel audio some chassis provide a front panel audio module that has separated connectors on each wire 27
Spdif_o s pdif out header 27
The front panel audio header supports hd audio by default if your chassis provides an ac 97 27
The front panel audio header supports intel high definition audio hd and ac 97 audio you may connect your chassis front panel audio module to this header make sure the wire assignments of the module con nector match the pin assignments of the motherboard header incorrect connection between the module connector and the motherboard header will make the device unable to work or even damage it 27
This header supports digital s pdif out and connects a s pdif digital audio cable provided by expan sion cards for digital audio output from your motherboard to certain expansion cards like graphics cards and sound cards for example some graphics cards may require you to use a s pdif digital audio cable for digital audio output from your motherboard to your graphics card if you wish to connect an hdmi display to the graphics card and have digital audio output from the hdmi display at the same time for information about connecting the s pdif digital audio cable carefully read the manual for your expan sion card 27
Com serial port header 28
Cord from the power outlet to prevent damage to the usb bracket 28
Do not plug the ieee 1394 bracket 2x5 pin cable into the usb header 28
F_usb1 f_usb2 usb headers 28
Hardware installation 28 28
Prior to installing the usb bracket be sure to turn off your computer and unplug the power 28
The com header can provide one serial port via an optional com port cable for purchasing the op tional com port cable please contact the local dealer 28
The headers conform to usb 2 1 specification each usb header can provide two usb ports via an optional usb bracket for purchasing the optional usb bracket please contact the local dealer 28
Chapter 2 bios setup 29
1 startup screen 30
A the logo screen default 30
B the post screen 30
2 the main menu 31
Bios setup program function keys 31
Samplebiosversion ga 880gm usb3ld11x 31
Advanced bios features 32
Exit without saving 32
Integrated peripherals 32
Keys for the main menu only 32
Load fail safe defaults 32
Load optimized defaults 32
Mb intelligent tweaker m i t 32
Pc health status 32
Pnp pciconfigurations 32
Power management setup 32
Save exit setup 32
Set supervisor password 32
Set user password 32
Standard cmos features 32
3 mb intelligent tweaker m i t 33
33 bios setup 33
Dent on your overall system configurations incorrectly doing overclock overvoltage may result in damage to cpu chipset or memory and reduce the useful life of these components this page is for advanced users only and we recommend you not to alter the default settings to prevent system instability or other unexpected results inadequately altering the settings may result in system s failure to boot if this occurs clear the cmos values and reset the board to default values 33
Note this item is present only when you install a cpu that supports this feature 33
System voltage control item to auto to optimize the system voltage settings 33
When the system voltage optimized item blinks in red it is recommended that you set the 33
Whether the system will work stably with the overclock overvoltage settings you made is depen 33
Igxconfiguration 34
Internal graphics mode 34
Onboard vga output connect 34
Surround view 34
Uma frame buffer size 34
Vga core clock control 34
Vga core clock mhz 34
Core performance boos 35
Cpb rati 35
Cpu clock ratio 35
Cpu frequency mhz 35
Cpu host clock control 35
Cpu northbridge freq 35
Ht link frequency 35
Ht link width 35
Memory clock 35
Pcie clock mhz 35
Set memory clock 35
Turbo cp 35
Allows you to set memory control mode 36
Bios setup 36 36
Cas latency 36
Dcts mode 36
Ddr3 timing items 36
Dramconfiguration 36
Ganged ganged sets memory control mode to single dual channel 36
Manual allows all ddr3 timing items below to be configurable 36
Minimum ras active time 36
Options are auto default 15t 30t 36
Options are auto default 1t 2t 36
Options are auto default 4t 12t 36
Options are auto default 4t 7t 36
Options are auto default 5t 12t 36
Options are auto default 5t 8t 10t 12t 36
Options are auto default 90ns 110ns 160ns 300ns 350ns 36
Options are auto default manual options are auto default manual 36
Ras to cas r w delay 36
Row precharge time 36
T 2t command timing 36
Trfc0 for dimm1 36
Trfc1 for dimm2 36
Twtr command delay 36
Unganged unganged sets memory control mode to two single channel default 36
Write recovery time 36
Bank interleaving 37
Channel interleaving 37
Cpu nb vid control 37
Ddr3 voltage control 37
Dqstrainingcontrol 37
Memclock tri stating 37
Northbridge volt control 37
Precharge time 37
Ras to ras delay 37
Row cycle time 37
Southbridge volt control 37
System voltage control 37
Cpu voltage control 38
Normal cpu vcore 38
4 standard cmos features 39
Date mm dd yy 39
Halt on 39
Ide channel 2 3 master slave 39
Memory 39
Time hh mm ss 39
5 advanced bios features 40
Amd c1e support 40
Auto auto if a cpu that supports hardware c1e is installed the bios will automatically enable the 40
Bios setup 40 40
Disabled disabled disables the c1e function 40
Enabled enabled if a cpu that supports hardware c1e is installed the bios will automatically enable the 40
Enables or disables the c1e cpu power saving function in system halt state when enabled the power consumption will be reduced during system halt state 40
Hardware c1e function if not the bios will enable the software c1e function hardware c1e function if not the bios will enable the software c1e function 40
Hardware c1e function if not the c1e function will be disabled default hardware c1e function if not the c1e function will be disabled default 40
Igxconfiguration 40
Note this item is present only when you install a cpu that supports this feature 40
The settings in this submenu are synchronous to those under the same items on the mb intelligent tweaker m i t main menu 40
Amdk8cool quietcontrol 41
Cpu core 41
Cpu core 1 2 3 4 41
Cpu core contro 41
Cpu unloc 41
Efi cd dvd boot option 41
First second third boot device 41
Hard disk boot priority 41
Password check 41
Virtualization 41
Away mode 42
Backup bios image to hdd 42
Full screen logo show 42
Hdd s m a r t capability 42
Init display first 42
43 bios setup 43
6 integrated peripherals 43
Ahci ahci configures the sata controllers to ahci mode advanced host controller interface 43
Ahci is an interface specification that allows the storage driver to enable advanced ahci is an interface specification that allows the storage driver to enable advanced 43
Configures the operating mode of the integrated sata2_0 sata2_3 controller 43
Enable native ide mode if you wish to install operating systems that support native enable native ide mode if you wish to install operating systems that support native 43
Enables or disables the integrated sata controller default enabled 43
J only for ga 880gm usb3l 43
Mode mode 43
Native ide native ide allows the sata controller to operate in native ide mode default 43
Onchip sata controller 43
Onchip sata port as esp 43
Onchip sata type sata2_0 sata2_3 connectors 43
Port0 as esp port1 as esp port2 as esp port3 as esp 43
Raid raid enables raid for the sata controller 43
Serial ata features such as native command queuing and hot plug serial ata features such as native command queuing and hot plug 43
This option is configurable only when this option is configurable only when onchip sata type is set to ahci enabled will speed up the hot plug detection of the connected sata device default disabled 43
Onboard lan boot rom 44
Onboard lan function 44
Smart lan lan cable diagnostic function 44
Onboard audio function 45
Onboard serial port 1 45
Onboard usb 3 controller etron ej168 usb controller j 45
Usb controllers 45
Usb legacy function 45
Usb storage function 45
7 power management setup 46
Acpi suspend type 46
Allows the system to be awakened from acpi s3 sleep state by a wake up signal from the installed usb device default enabled 46
Allows the system to be awakened from an acpi sleep state by a wake up signal from a modem that supports wake up function default disabled 46
Allows the system to be awakened from an acpi sleep state by a wake up signal from a pci or pcie de vice note to use this function you need an atx power supply providing at least 1a on the 5vsb lead default enabled 46
Bios setup 46 46
Button is pressed for less than 4 seconds the system will enter suspend mode button is pressed for less than 4 seconds the system will enter suspend mode 46
Configures the way to turn off the computer in ms dos mode using the power button 46
Delay 4 sec delay 4 sec press and hold the power button for 4 seconds to turn off the system if the power 46
In s1 sleep state the system appears suspended and stays in a low power mode in s1 sleep state the system appears suspended and stays in a low power mode 46
In s3 sleep state the system appears to be off and consumes less power than in in s3 sleep state the system appears to be off and consumes less power than in 46
Instant off instant off press the power button and then the system will be turned off instantly default 46
Its working state exactly where it was left off its working state exactly where it was left off 46
Modem ring resume 46
Note supported on windows 7 vista operating system only 46
Pme event wake up 46
S1 pos s1 pos enables the system to enter the acpi s1 power on suspend sleep state 46
S3 str s3 str enables the system to enter the acpi s3 suspend to ram sleep state default 46
Soft off by power button 46
Specifies the acpi sleep state when the system enters suspend 46
The s1 state when signaled by a wake up device or event the system resumes to the s1 state when signaled by a wake up device or event the system resumes to 46
The system can be resumed at any time the system can be resumed at any time 46
Usb wake up from s3 46
Ac back function 47
Erp support 47
Hpet suppor 47
Kb power on password 47
Power on by alarm 47
Power on by keyboard 47
Power on by mouse 47
4 5 7 9 10 11 12 14 15 3 4 5 7 9 10 11 12 14 15 assigns irq 3 4 5 7 9 10 11 12 14 15 to the first pci slot 48
4 5 7 9 10 11 12 14 15 3 4 5 7 9 10 11 12 14 15 assigns irq 3 4 5 7 9 10 11 12 14 15 to the second pci slot 48
8 pnp pci configurations 48
8 pnp pciconfigurations 48
Auto bios auto assigns irq to the first pci slot default 48
Auto bios auto assigns irq to the second pci slot default 48
Bios setup 48 48
Pci1irqassignment 48
Pci2irqassignment 48
49 bios setup 49
9 pc health status 49
Allows the system to emit warning sound if the cpu system fan is not connected or fails check the fan condition or fan connection when this occurs default disabled 49
Case opened 49
Cpu system fan fail warning 49
Cpu warning temperature 49
Current cpu system fan speed rpm 49
Current system cpu temperature 49
Current voltage v vcore ddr3 1 v 3 v 12v 49
Displays current cpu system fan speed 49
Displays current system cpu temperature 49
Displays the current system voltages 49
Displays the detection status of the chassis intrusion detection device attached to the motherboard ci header if the system chassis cover is removed this field will show yes otherwise it will show no to clear the chassis intrusion status record set reset case open status to enabled save the settings to the cmos and then restart your system 49
Enables or disables the cpu overheating protection function when enabled the cpu core voltage and ratio will be reduced when the cpu is overheated default enabled 49
Hardware thermal control 49
Keeps or clears the record of previous chassis intrusion status enabled clears the record of previous chassis intrusion status and the case opened field will show no at next boot default disabled 49
Reset case open status 49
Sets the warning threshold for cpu temperature when cpu temperature exceeds the threshold bios will emit warning sound options are disabled default 6 49
Cpu smart fan control 50
Cpu smart fan mode 50
10 load fail safe defaults 51
11 load optimized defaults 51
51 bios setup 51
Key to load the optimal bios default settings the bios defaults settings help the system to operate in optimum state always load the optimized defaults after updating the bios or after clearing the cmos values 51
Key to load the safest bios default settings in case system instability occurs you may try to load fail safe defaults which are the safest and most stable bios settings for the motherboard 51
12 set supervisor user password 52
Again the message password disabled will appear indicating the password has been can celled 52
Bios setup 52 52
Supervisor password 52
The bios setup program allows you to specify two separate passwords 52
User password 52
When a system password is set and the when a system password is set and the password check item in advanced bios features is set to setup you must enter the supervisor password for entering bios setup and making bios changes 52
When the when the password check item is set to system you must enter the supervisor password or user password at system startup and when entering bios setup 52
When the when the password check item is set to system you must enter the supervisor password or user password at system startup to continue system boot in bios setup you must enter the supervisor password if you wish to make changes to bios settings the user password only allows you to view the bios settings but not to make changes 52
13 save exit setup 53
14 exit without saving 53
53 bios setup 53
To return to the bios setup main menu 53
1 installing chipset drivers 55
Chapter 3 drivers installation 55
2 application software 56
3 technical manuals 56
4 contact 57
5 system 57
6 download center 58
7 new utilities 58
1 xpress recovery2 59
Beforeyoubegin 59
Chapter 4 unique features 59
Installationandconfiguration 59
Systemrequirements 59
2 1 updating the bios with the q flash utility 62
2 1 updatingthebioswiththeq flashutility 62
2 bios update utilities 62
A before you begin 62
63 unique features 63
B updating the bios 63
Do not turn off or restart the system when the system is reading updating the bios donotremovetheusbflashdriveorharddrivewhenthesystemisupdatingthebios 63
Key during the post to access q flash 63
Makesurethebiosupdatefilematchesyourmotherboardmodel 63
Step 3 when the update process is complete press any key to return to the main menu 63
The save main bios to drive option allows you to save the current bios file q flash only supports usb flash drive or hard drives using fat32 16 12 file system if the bios update file is saved to a hard drive in raid ahci mode or a hard drive attached to 63
To begin the bios update the monitor will display the update process 63
When updating the bios choose the location where the bios file is saved the following procedure as sumes that you save the bios file to a usb flash drive 63
To exit q flash and reboot the system as the system boots you should see the new bios version is present on the post screen 64
To load bios defaults 64
To load bios defaults system will re detect all peripheral devices after a bios update so we recommend that you reload bios defaults 64
To save settings to cmos and exit bios setup the proce dure is complete after the system restarts 64
Unique features 64 64
2 2 updating the bios with the bios utility 65
A before you begin 65
B using bios 65
C after updating the bios 65
3 easytune 6 66
Gigabyte s easytune 6 is a simple and easy to use interface that allows users to fine tune their system settings or do overclock overvoltage in windows environment the user friendly easytune 6 interface also includes tabbed pages for cpu and memory information letting users read their system related information without the need to install additional software 66
Tab function 66
Tabs information 66
The easytune 6 interface 66
Unique features 66 66
4 q share 67
Directionsforusingq share 67
Options descriptions 67
5 smart recovery 68
6 auto green 69
69 unique features 69
Auto green is an easy to use tool that provides users with simple options to enable system power savings via a bluetooth cell phone when the phone is out of the range of the computer s bluetooth receiver the sys tem will enter the specified power saving mode 69
Configuring other bluetooth settings 69
Configuring the bluetooth cell phone key 69
Selecting a system energy saving mode 69
Theconfigurationdialogbox 69
7 cloud oc 70
A launching cloud oc 70
And logging in to the cloud oc server you can easily access three major functions of cloud oc including tuner system tweaking system info system monitoring and control system status control 70
B directions for us 70
Bluetoot 70
Cloud o 70
Is an easy to use overclocking utility designed for system overclock ing via virtually any internet connected device such as a smart phone iphone note book pc etc by simply connecting to an internet browser via lan wireless lan or 70
Unique features 70 70
1 1 configuring the onboard sata controller 71
1 1 configuringtheonboardsatacontroller 71
1 configuring sata hard drive s 71
1 configuringsataharddrive s 71
A installing sata hard drive s in your computer 71
Before you begin 71
Chapter 5 appendix 71
Toconfiguresataharddrive s followthestepsbelow 71
Appendix 72 72
B configuringsatacontrollermodeinbiossetup 72
Figure 1 72
Make sure to configure the sata controller mode correctly in system bios setup 72
Step 2 save changes and exit bios setup 72
The bios setup menus described in this section may differ from the exact settings for your moth erboard the actual bios setup menu options you will see shall depend on the motherboard you have and the bios version 72
To enter bios setup during the post power on self test un der integrated peripherals make sure onchip sata controller is enabled to enable raid set onchip sata type to raid figure 1 72
C configuringraidsetinraidbios 73
Appendix 74 74
Figure 4 74
Figure 5 74
In the lddefinemenu use the up or down arrow key to move to an item for further configuration figure 5 74
To access the lddefinemenu 74
Appendix 76 76
Delete an array the delete array menu option allows for deletion of disk array assignments 76
Deleting an existing disk array could result in loss of data record all array information including the array type the disk members and stripe block size in case you wish to undo a deletion 76
Figure 10 76
Figure 9 76
If you are sure to delete the array or other keys to abort 76
In the main menu to enter the delete ld menu then highlight the array you 76
The viewlddefinationmenu will appear as shown in figure 10 showing which drives are assigned to 76
To return to main menu 76
View drive assignments the view drive assignments option in the main menu displays whether the attached hard drives are as signed to a disk array or are unassigned under the assignment column drives are labeled with their as signed disk array or shown as free if unassigned 76
1 2 installing the sata raid ahci driver and operating system 77
A installing windows xp 77
B installing windows 7 vista 78
2 1 configuring 2 4 5 7 channel audio 81
2 1 configuring2 4 5 7 channelaudio 81
2 configuring audio input and output 81
2 configuringaudioinputandoutput 81
A configuringspeakers 81
B configuringspdifout 82
C configuringsoundeffect 82
2 2 configuring microphone recording 83
2 2 configuringmicrophonerecording 83
D activating an ac 97 front panel audio module 83
E muting the back panel audio for hd audio only 83
Enabling stereo mix 84
2 3 using the sound recorder 85
A recording sound 85
B playing the recorded sound 85
3 1 frequently asked questions 86
3 1 frequentlyaskedquestions 86
3 troubleshooting 86
Appendix 86 86
To read more faqs for your motherboard please go to the support downloads faq page on gigabyte s website 86
3 2 troubleshooting procedure 87
87 appendix 87
If you encounter any troubles during system startup follow the troubleshooting procedure below to solve the problem 87
Appendix 88 88
If the procedure above is unable to solve your problem contact the place of purchase or local deal er for help or go to the support downloads technical support page to submit your question our customer service staff will reply you as soon as possible 88
95 appendix 95
Contact us 95
Appendix 96 96
Gigabyte global service system 96
To submit a technical or non technical sales market ing question please link to http ggts gigabyte com tw then select your language to enter the system 96

Gigabyte GA-880GM-D2H (rev.3.1) Инструкция по эксплуатации онлайн [2/96] 42060

Содержание

Похожие устройства
