Hardware Installation - 10 -
1-2 Product Specications
CPU
Support for AM3 processors:
AMD Phenom
™
II processor/ AMD Athlon
™
II processor/
(Go to GIGABYTE's website for the latest CPU support list.)
Hyper Transport Bus
5200 MT/s
Chipset
North Bridge: AMD 790X
South Bridge: AMD SB750
Memory
4 x 1.5V DDR3 DIMM sockets supporting up to 16 GB of system memory
(Note 1)
Dual channel memory architecture
Support for DDR3 1866 (O.C.)
(Note 2)
/1333/1066 MHz memory modules
(Go to GIGABYTE's website for the latest memory support list.)
Audio
Realtek ALC889 codec
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF In/Out
Support for CD In
LAN
1 x RTL8111D chip (10/100/1000 Mbit)
Expansion Slots
1 x PCI Express x16 slot, running at x16 (PCIEX16)
(Note 3)
1 x PCI Express x16 slot, running at x8 (PCIEX8)
(Note 3)
(The PCIEX16 and PCIEX8 slots conform to PCI Express 2.0 standard.)
2 x PCI Express x1 slots
3 x PCI slots
Multi-Graphics
Support for ATI CrossFireX
™
technology
Technology
Storage Interface
Chipset:
- 1 x IDE connector supporting ATA-133/100/66/33 and up to 2 IDE devices
- 6 x SATA 3Gb/s connectors (SATA2_0, SATA2_1, SATA2_2, SATA2_3,
SATA2_4, SATA2_5) supporting up to 6 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, RAID 5, RAID 10, and JBOD
JMicron JMB362 chip:
- 2 x eSATA 3Gb/s connectors on the back panel supporting up to
2 SATA 3Gb/s devices
- Support for SATA RAID 0, RAID 1, and JBOD
iTE IT8720 chip:
- 1 x oppy disk drive connector supporting up to 1 oppy disk drive
