Connecting the power cord
1 Connect the AC cord into the AC input on the
back of the set.
2 Connect the plug to the wall outlet as shown.
Setting up the remote control
1 Open the cover on the back of the remote unit.
2
Insert two AAA batteries (supplied) to match the
polarity indicated inside the battery compartment.
Getting started watching your TV Monitor
* You can also adjust these settings using the front control panel. Please see "Side of set" on page 3
for details.
Enjoying analog TV Monitor
Connecting an antenna/cable
Connect the antenna cable to the appropriate antenna
terminal on the back of the TV Monitor set as shown
below.
Analog
1
Power
a. Turn on the power switch beneath the screen.
b. Press the
power button, number keys or channel
up / down button on the remote control.
2
Setup Wizard
The first time you switch on the TV Monitor, the Setup
Wizard will guide you to complete the language selection
and channel scanning.
Press the OK key to begin the setup process.
Step 1. Select the setup language you prefer.
Step 2. Please select country.
Step 3.
Ensure that your co-axial cables are connected
correctly before proceeding.
Step 4. Scan for analog channels.
Step 5. Setup is now complete. You are ready to
begin watching TV Monitor.
If you leave the setup process before it is complete,
you will be given a choice of options:
1. Resume setup
2. Resume setup wizard at next startup
3. Exit and do not remind me
Select an option and press
OK to exit.
3
Changing channels
a. Press 0 - 9 on the remote control to select a
channel. The channel changes after 2 seconds.
Press
ENTER
to select the channel immediately.
b. Pressing the channel (
CH
) up / down button
on the remote control will also change the
channel.
4
Adjusting the volume
Adjust the volume level using the (
VOL )
up/down
button on the remote control.
1
2
4
1
1
3
* Setup may vary due to local broadcast differences.
Basic connections
6
