3 Getting Started DGS-1210 series Metro Ethernet Managed Switch User Manual

In order to login and configure the switch via an Ethernet connection, the PC must have an IP address in the

same subnet as the switch. For example, if the switch has an IP address of 10.90.90.90, the PC should have

an IP address of 10.x.y.z (where x/y is a number between 0 ~ 254 and z is a number between 1 ~ 254), and

a subnet mask of 255.0.0.0. Enter 10.90.90.90 (the factory default IP address) in the address bar of your

web browser and press <Enter>.

Figure 3.2 –Enter the IP address 10.90.90.90 in the web browser

NOTE: The switch's factory default IP address is

10.90.90.90 with a subnet mask of 255.0.0.0 and

a default gateway of 0.0.0.0.

When the following logon dialog box appears, enter the password and choose the language of the Web-

based Management interface then click OK.

By default, the Username and Password are empty.

Figure 3.3 – Logon Dialog Box

Web-based Management

By clicking the OK button in Logon Dialog Box, you will enter the Web-based Management interface. Please

refer to Chapter 4 Configuration for detailed instructions.
