DGS-1510/ME Series Metro Ethernet Switch Hardware Installation Guide
40
Feature Description
DGS-1510-28XS/ME: 95.24 Mpps (Mega Packets Per Second)
DGS-1510-52L/ME: 104.16 Mpps (Mega Packets Per Second)
DGS-1510-52X/ME: 130.95 Mpps (Mega Packets Per Second)
Priority Queues
8 Priority Queues per port.
MAC Address Table
Supports 8K MAC addresses.
Supports 512 Static MAC addresses.
Virtual Stacking / Clustering
Supports D-Link Single IP Management version 1.6.
Manage up to 32 devices in a virtual stack with a single IP address.
LED Indicators
Location LED Indicative Color Status Description
Per Device Power Green
Solid Light Power on
Blinking Performing System Self-test.
Light off Power off
Console Green
Solid Light Console on
Light off Console off
RPS Green
Solid Light RPS in use
Light off RPS off
Fan Green
Solid Light Diagnostics pass. Normal operation.
Red
Solid Light Fan failure
Port LED Mode
Indicator
(DGS-1510-
28LP/ME and DGS-
1510-28XMP/ME
Only)
An LED Mode Select Button to switch two modes in turn for all
10/100/1000Mbps ports on the:
• Link/Act/Speed Mode (1)
• PoE Mode (2)
Green
Solid Light (1) A LED Mode Select Button to switch
Link/Act/Speed Mode.
Solid Light (2) A LED Mode Select Button to switch
PoE Mode.
LED per Copper
RJ45 Port
(10/100/1000Mbps)
Link/Act/Speed
Mode
Green
Solid Light When there is a secure connection (or
link) to 1000Mbps Ethernet device at
any of the ports.
Blinking When there is reception or
transmission of data occurring at
1000Mbps.
Amber
Solid Light When there is a secure connection (or
link) to 10/100Mbps Ethernet device at
any of the ports.
Blinking When there is reception or
transmission of data occurring at
10/100Mbps.
Off
Light off No link
PoE Mode
(DGS-1510-
28LP/ME and DGS-
1510-28XMP/ME
Green
Solid Light Power feeding
Amber
Solid Light Error Condition
Off
Light Off No Power feeding
