DGS-1510/ME Series Metro Ethernet Switch Hardware Installation Guide
41
Location LED Indicative Color Status Description
only)
LED per SFP Port
(1000Mbps)
Link/Act Green
Solid Light When there is a secure connection (or
link) to 1000Mbps Ethernet device at
any of the ports.
Blinking When there is reception or
transmission of data occurring at
1000Mbps.
Off
Light off No link
LED per SFP+
Port
(1/10Gbps)
Link/Act Green
Solid Light When there is a secure connection (or
link) to 10Gbps Ethernet device at any
of the ports.
Blinking When there is reception or
transmission (i.e. Activity--Act) of data
occurring at a 10Gbps port.
Amber
Solid Light When there is a secure connection (or
link) to 1Gbps Ethernet device at any
of the ports.
Blinking When there is reception or
transmission (i.e. Activity--Act) of data
occurring at a 1Gbps port.
Off
Light off No link
Port Functions
Feature Description
Console Port
RJ45 interface for Out-Of-Band (OOB) CLI configuration.
Copper RJ45 Ports
Compliant with the following standards:
• IEEE 802.3 compliance
• IEEE 802.3u compliance
• IEEE 802.3ab compliance
• IEEE 802.3az compliance (100/1000Mbps)
• Auto-negotiation
• Auto MDI/MDIX
• IEEE 802.3x Flow Control support for Full-Duplex mode
• IEEE 802.3af compliance (DGS-1510-28LP/ME and DGS-1510-
28XMP/ME only)
• IEEE 802.3at compliance (DGS-1510-28LP/ME and DGS-1510-
28XMP/ME only)
SFP Ports
Compliant with the following standards:
• IEEE 802.3u compliance (DGS-1510-XS/ME 1-24 ports)
• IEEE 802.3z compliance
• Support Auto-negotiation for full-duplex and flow control
operations
SFP Transceivers Supported:
• DEM-302S-LX (1000BASE-LX, Single-mode, 2km)
