xStack® DGS-3120 Series Layer 3 Managed Gigabit Ethernet Switch Web UI Reference Guide

342

Figure 8-32 ND Snooping Maximum Entry Settings window

The fields that can be configured are described below:

Parameter Description

Unit

Select the unit you want to configure. (EI Mode Only)

From Port / To Port

Use the drop-down menus to select a range of ports that require a restriction on the

maximum number of entries that can be learned with ND snooping.

Maximum Entry (1-50) Enter the maximum entry value. Tick the No Limit check box to have unlimited

maximum number of the learned entries.

Click the Apply button to accept the changes made.

ND Snooping Entry

This window is used to view dynamic entries on specific ports.

To view this window, click Security > IP-MAC-Port Binding (IMPB) > ND Snooping > ND Snooping Entry as

shown below:

Figure 8-33 ND Snooping Entry window

The fields that can be configured are described below:

Parameter Description
