D-Link DAP-3320 [6/142] Package contents

1D-Link DAP-3320 User Manual

Section 1 - Product Overview

Note: Using a power supply with a dierent voltage rating or PoE injector than the one included with the DAP-3320 will cause

damage and void the warranty for this product.

Package Contents

DAP-3320 Wireless PoE Outdoor Access point

Quick Installation Guide

Grounding Wire

Power Over Ethernet Injector (included with

some models)

48 V/0.5 A Power Adapter (included with

some models)

Wall mounting bracket with

mounting kit with two plastic

mounting ties

If any of the above items are missing, please contact your reseller.
